Запчасти Komatsu WA380-5 КАБИНА ROPS (ДВЕРЬ, LHS) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

421-56-H4A00

DOOR

SN: H50228-UP

1шт.

1

421-56-H4900

DOOR ASSEMBLY

SN: H50228-UP

1шт.

2

421-56-H4940

SLIDING WINDOW

SN: H50228-UP

1шт.

2A

421-56-H0S53

GRIP

SN: H50228-UP

1шт.

|$5

423-56-H1J90

GUIDE ROD

SN: H50228-UP

1шт.

2B

421-56-H0S51

GLASS

SN: H50228-UP

1шт.

2C

421-56-H0S65

GLASS

SN: H50228-UP

1шт.

3

421-56-H4560

GRIP

SN: H50228-UP

1шт.

4

419-925-HP06

GRIP SHELL, LHS WITH BOWDEN CABLE

SN: H50228-UP

1шт.

5

421-56-H0R74

SEAL

SN: H50228-UP

1шт.

6

421-56-H0R78

REMOTE ACTUATION

SN: H50228-UP

1шт.

7

421-56-H0R91

ROD

SN: H50228-UP

1шт.

8

421-56-H0R92

TRACTION

SN: H50228-UP

1шт.

9

421-56-H0R93

LEVER

SN: H50228-UP

1шт.

10

421-56-H4M60

UNDERLAY

SN: H50228-UP

1шт.

11

421-56-H0R78

REMOTE ACTUATION

SN: H50228-UP

2шт.

12

421-56-H0R94

LOCK ASSEMBLY

SN: H50228-UP

1шт.

13

421-56-H0R95

COVER

SN: H50228-UP

1шт.

14

421-56-H0R81

BEARING

SN: H50228-UP

1шт.

15

421-56-H0R82

WASHER

SN: H50228-UP

1шт.

16

01220-40816

BOLT

SN: H50228-UP

1шт.

17

421-56-H0R83

SCREW

SN: H50228-UP

2шт.

18

421-56-H0P73

CAP

SN: H50228-UP

2шт.

19

425-56-H0P43

SCREW

SN: H50228-UP

4шт.

20

421-56-H0R63

BOLT

SN: H50228-UP

2шт.

21

425-56-H0P04

NUT

SN: H50228-UP

4шт.

22

01580-00403

NUT

SN: H50228-UP

1шт.

23

01641-20405

WASHER

SN: H50228-UP

1шт.

24

421-56-H0R84

SPRING

SN: H50228-UP

2шт.

25

421-56-H0R85

DISC

SN: H50228-UP

3шт.

26

421-56-H0R86

TOOTH WASHER

SN: H50228-UP

2шт.

27

421-56-H0R26

SCREW

SN: H50228-UP

2шт.

28

421-56-H4240

CLADDING

SN: H50228-UP

1шт.

29

421-56-H4260

COVER

SN: H50228-UP

1шт.

30

421-56-H0R96

SCREW

SN: H50228-UP

1шт.

31

421-56-H0R28

WASHER

SN: H50228-UP

2шт.

32

421-56-H0R88

NUT

SN: H50228-UP

1шт.

33

01580-00605

NUT

SN: H50228-UP

1шт.

34

42Y-56-H0P03

CAP

SN: H50228-UP

2шт.

35

421-56-H0P98

CLIP

SN: H50228-UP

8шт.

36

425-56-H0P56

SCREW

SN: H50228-UP

8шт.

37

421-56-H0R87

PLUG

SN: H50228-UP

4шт.

38

421-56-H4510

SEAL

SN: H50228-UP

1шт.

39

421-56-H4950

SHEET

SN: H50228-UP

1шт.

40

421-56-H0R88

NUT

SN: H50228-UP

4шт.

41

421-56-H0P66

DISC

SN: H50228-UP

4шт.

42

09690-P0500

CHARACTERS

SN: H50228-UP

1шт.

43

421-56-H0R89

HANDLE

SN: H50228-UP

1шт.

44

421-56-H4M70

LINING

SN: H50228-UP

1шт.

45

421-56-11350

SEAL

SN: H50228-UP

1шт.

46

421-56-H0S81

ANGLE

SN: H50228-UP

2шт.
