Запчасти Komatsu WA380-5 ТРАНСМИССИЯ (2 И 3 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-12-20001

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20000

TRANSMISSION ASS'Y

SN: 60001-(10319)

1шт.

|1

714-12-20011

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-(10319)

1шт.

|1

714-12-20101

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20100

TRANSMISSION ASS'Y,(FOR TACHOGRAPH)

SN: 60001-(10319)

1шт.

|1

714-12-20111

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20110

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)

SN: 60001-(10319)

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

714-12-22030

CLUTCH,2ND AND 3RD

SN: 60001-UP

1шт.

1

714-12-22131

SHAFT AND CYLINDER A,2ND AND 3RD

SN: 60001-UP

1шт.

|1

0

SHAFT,LOWER

SN: 60001-UP

1шт.

|1

0

ORIFICE

SN: 60001-UP

1шт.

|1

0

BALL

SN: 60001-UP

2шт.

|1

0

HOUSING

SN: 60001-UP

1шт.

|1

0

ORIFICE

SN: 60001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: 60001-UP

2шт.

3

714-12-19711

DISC

SN: 60001-UP

14шт.

4

714-16-19730

PLATE,SEPARATE

SN: 60001-UP

16шт.

5

419-15-12133

SPRING,WAVE

SN: 60001-UP

14шт.

6

714-12-12610

PLATE,END

SN: 60001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 60001-UP

2шт.

8

714-16-19220

RING

SN: 60001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 60001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 60001-UP

4шт.

11

714-23-19430

BEARING,NEEDLE

SN: 60001-UP

2шт.

12

714-12-22461

GEAR¤ 53 TEETH,2ND

SN: 60001-UP

1шт.

13

714-12-22451

GEAR¤ 40 TEETH,3RD

SN: 60001-UP

1шт.

14

714-12-22530

GEAR¤ 49 TEETH,OUTPUT

SN: 60001-UP

1шт.

15

714-12-22541

GEAR¤ 28 TEETH,4TH

SN: 60001-UP

1шт.

16

14X-14-19123

BEARING

SN: 60001-UP

1шт.

17

714-07-29350

BEARING

SN: 60001-UP

1шт.

18

419-15-12122

RING (K1)

SN: 60001-UP

3шт.
