Запчасти Komatsu WA380-5 ТРАНСМИССИЯ (1 И 4 МУФТА) ТРАНСМИССИЯ
№
Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-12-20001
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20000
TRANSMISSION ASS'Y
SN: 60001-(10319)
1шт.
|1
714-12-20011
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-(10319)
1шт.
|1
714-12-20101
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-(10319)
1шт.
|1
714-12-20111
TRANSMISSION ASS'Y
SN: (10320)-UP
1шт.
|1
714-12-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-(10319)
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|1
714-12-22020
CLUTCH,1ST AND 4TH
SN: 60001-UP
1шт.
1
714-12-22121
SHAFT AND CYLINDER A,1ST AND 4TH
SN: 60001-UP
1шт.
|1
0
SHAFT,UPPER
SN: 60001-UP
1шт.
|1
0
HOUSING
SN: 60001-UP
1шт.
|1
0
ORIFICE
SN: 60001-UP
1шт.
|1
0
BALL
SN: 60001-UP
2шт.
2
714-07-22661
PISTON,RANGE
SN: 60001-UP
2шт.
11
714-08-19560
WASHER
SN: 60001-UP
1шт.
14
714-11-12720
SPACER
SN: 60001-UP
1шт.
15
714-07-22550
SNAP RING
SN: 60001-UP
1шт.
16
714-12-22441
GEAR¤ 31 TEETH,4TH
SN: 60001-UP
1шт.
17
714-12-22431
GEAR¤ 26 TEETH,1ST
SN: 60001-UP
1шт.
18
714-12-22511
GEAR¤ 37 TEETH,2ND
SN: 60001-UP
1шт.
20
714-12-29340
BEARING
SN: 60001-UP
1шт.
Выбрано товаров: 36
