Запчасти Komatsu WA380-5 ТРАНСМИССИЯ (МУФТА ВПЕРЕД/РЕВЕРС) (С БЛОКИР.-UP) СИЛОВАЯ ПЕРЕДАЧА
№
Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$6
714-12-20014
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 62274-UP
1шт.
|$7
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: (10320)-00062273
1шт.
|$8
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111306))
1шт.
|$9
0
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: ((10320)-(111258))
1шт.
|$10
714-12-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-(10319)
1шт.
|$11
714-12-20313
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: 62274-UP
1шт.
|$12
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: 60001-62273
1шт.
|$13
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: (60001-(111306))
1шт.
|$14
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)
SN: (60001-(111258))
1шт.
|$$11
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.
-1шт.
|$23
714-12-22050
CLUTCH ASS'Y,FORWARD AND REVERSE
SN: 60001-UP
1шт.
1
714-12-22151
SHAFT AND CYLINDER A
SN: 60001-UP
1шт.
1
0
SHAFT,INPUT
SN: 60001-UP
1шт.
1
0
SCREW
SN: 60001-UP
2шт.
1
0
ORIFICE
SN: 60001-UP
1шт.
1
0
HOUSING
SN: (110377)-UP
1шт.
1
0
HOUSING
SN: 60001-(110376)
1шт.
3
714-07-22652
PISTON,FOWARD AND REVERSE
SN: 60001-UP
2шт.
7
714-07-22720
PLATE
SN: 60001-UP
2шт.
14
714-11-12720
SPACER
SN: 60001-UP
1шт.
15
714-07-22711
SPACER
SN: 60001-UP
1шт.
17
714-12-22421
GEAR, 40 TEETH,FORWARD
SN: 60001-UP
1шт.
18
714-12-22411
GEAR, 31 TEETH,REVERSE
SN: 60001-UP
1шт.
Выбрано товаров: 38
