Запчасти Komatsu WA380-5 МОДУЛИРУЮЩИЙ КЛАПАН СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$11

714-12-20004

TRANSMISSION ASS'Y

SN: 62274-UP

1шт.

|$12

714-12-20003

TRANSMISSION ASS'Y

SN: (10320)-00062273

1шт.

|$13

0

TRANSMISSION ASS'Y

SN: ((10320)-(111306))

1шт.

|$14

0

TRANSMISSION ASS'Y

SN: ((10320)-(111258))

1шт.

|$15

714-12-20000

TRANSMISSION ASS'Y

SN: 60001-(10319)

1шт.

|$16

714-12-20014

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 62274-UP

1шт.

|$17

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: (10320)-00062273

1шт.

|$18

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111306))

1шт.

|$19

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111258))

1шт.

|$20

714-12-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-(10319)

1шт.

|$21

714-12-20303

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 62274-UP

1шт.

|$22

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-62273

1шт.

|$23

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111306))

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111258))

1шт.

|$25

714-12-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 62274-UP

1шт.

|$26

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 60001-62273

1шт.

|$27

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111306))

1шт.

|$28

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111258))

1шт.

|$$20

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$43

714-07-25021

VALVE ASS'Y

SN: 60001-UP

1шт.

|$44

0

VALVE ASS'Y

SN: (60001-(111210))

1шт.

|$45

0

VALVE ASS'Y,MAIN

SN: (60001-61141)

1шт.

|$46

0

VALVE ASS'Y,MAIN

SN: (60001-60352)

1шт.

|$$25

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-59A0 AND F4350-60A0.

-1шт.

|$48

714-07-25031

VALVE ASS'Y,(WITH LOCK-UP)

SN: 61142-UP

1шт.

|$49

0

VALVE ASS'Y,(WITH LOCK-UP)

SN: (61142-(111210))

1шт.

|$50

0

VALVE ASS'Y,(WITH LOCK-UP)

SN: 60001-61141

1шт.

|$51

0

VALVE ASS'Y,(WITH LOCK-UP)

SN: (60001-60352)

1шт.

|$$30

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-59A1 AND F4350-60A0.

-1шт.

|$53

714-07-26000

VALVE ASS'Y,MODULATION

SN: (10320)-UP

1шт.

|$54

0

VALVE ASS'Y,MODULATION

SN: 60001-(10319)

1шт.

1

0

BODY

SN: 60001-UP

1шт.

2

07042-20108

PLUG

SN: 60001-UP

2шт.

3

14X-15-15850

PLUG

SN: 60001-UP

1шт.

4

07002-03034

O-RING (K2)

SN: 60001-UP

1шт.

5

714-07-25230

VALVE

SN: (10320)-UP

1шт.

5

0

VALVE

SN: 60001-(10319)

1шт.

6

426-15-15490

VALVE

SN: 60001-UP

1шт.

7

198-15-15770

SPRING, (L= 30.0)

SN: 60001-UP

1шт.

8

426-15-15480

VALVE

SN: 60001-UP

1шт.

9

198-15-15570

SHIM, 0.50MM

SN: 60001-UP

5шт.

10

426-15-16251

SPRING, (L=122.0)

SN: 60001-UP

1шт.

11

426-15-16261

SPRING, (L=108.0)

SN: 60001-UP

1шт.

12

426-15-15810

PLUG

SN: 60001-UP

1шт.

13

07002-03034

O-RING (K2)

SN: 60001-UP

1шт.

14

12H-15-14130

SPOOL

SN: 60001-UP

1шт.

15

104-15-25490

VALVE

SN: 60001-UP

1шт.

16

125-15-15290

SPRING

SN: 60001-UP

1шт.

17

104-15-25480

VALVE

SN: 60001-UP

1шт.

18

14X-15-16210

SPRING

SN: 60001-UP

1шт.

19

12H-15-14140

GUIDE

SN: 60001-UP

1шт.

20

14X-15-15850

PLUG

SN: 60001-UP

2шт.

21

07002-03034

O-RING (K2)

SN: 60001-UP

2шт.
