Запчасти Komatsu WA380-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ (ХОЛОДН. МЕСТН. (A) СПЕЦ-Я.) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

714-12-20303

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 62274-UP

1шт.

|$6

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-62273

1шт.

|$7

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111306))

1шт.

|$8

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111258))

1шт.

|$9

714-12-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 62274-UP

1шт.

|$10

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 60001-62273

1шт.

|$11

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111306))

1шт.

|$12

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111258))

1шт.

|$19

714-12-25600

VALVE ASS'Y

SN: 60001-UP

1шт.

1

714-12-25150

BODY

SN: 60001-UP

1шт.

2

714-07-15410

VALVE

SN: 60001-UP

1шт.

3

714-07-15420

SPRING

SN: 60001-UP

1шт.

4

714-07-15840

COVER

SN: 60001-UP

2шт.

5

01010-80820

BOLT

SN: 60001-UP

4шт.

6

01643-30823

WASHER

SN: 60001-UP

4шт.

7

07000-73030

O-RING (K2)

SN: 60001-UP

2шт.

8

714-12-25480

FILTER

SN: 60001-UP

1шт.

9

714-12-25470

SOLENOID VALVE

SN: 60001-UP

1шт.

10

07000-12012

O-RING (K2)

SN: 60001-UP

1шт.

11

07000-12014

O-RING (K2)

SN: 60001-UP

1шт.

12

07000-12016

O-RING (K2)

SN: 60001-UP

1шт.

13

07000-12018

O-RING (K2)

SN: 60001-UP

1шт.

14

203-60-62190

O-RING (K2)

SN: 60001-UP

1шт.

15

07002-11423

O-RING (K2)

SN: 60001-UP

1шт.

16

02720-40104

PLUG

SN: 60001-UP

4шт.

17

07042-80108

PLUG

SN: 60001-UP

2шт.

18

04434-50610

CLIP

SN: 60001-UP

1шт.

19

08193-21012

CLIP

SN: 60001-UP

1шт.

20

01435-01016

BOLT

SN: 60001-UP

2шт.
