Запчасти Komatsu WA380-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$7

714-12-20004

TRANSMISSION ASS'Y

SN: 62274-UP

1шт.

|$8

714-12-20003

TRANSMISSION ASS'Y

SN: (10320)-00062273

1шт.

|$9

0

TRANSMISSION ASS'Y

SN: ((10320)-(111306))

1шт.

|$10

0

TRANSMISSION ASS'Y

SN: ((10320)-(111258))

1шт.

|$11

714-12-20000

TRANSMISSION ASS'Y

SN: 60001-(10319)

1шт.

|$12

714-12-20014

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 62274-UP

1шт.

|$13

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: (10320)-00062273

1шт.

|$14

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111306))

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111258))

1шт.

|$16

714-12-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-(10319)

1шт.

|$$12

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$42

714-07-25401

VALVE ASS'Y

SN: (110435)-UP

1шт.

|$43

0

VALVE ASS'Y

SN: 60001-(110434)

1шт.

|$44

714-07-25461

BODY

SN: (110435)-UP

1шт.

|$45

714-07-25460

BODY

SN: 60001-(110434)

1шт.

1

0

BODY

SN: (110435)-UP

1шт.

1

0

BODY

SN: 60001-(110434)

1шт.

2

07042-80108

PLUG

SN: (110435)-UP

2шт.

2

07043-70108

PLUG

SN: 60001-(110434)

2шт.

3

714-07-15410

VALVE

SN: 60001-UP

1шт.

4

714-07-15420

SPRING

SN: 60001-UP

1шт.

5

714-07-15430

CHOKE

SN: 60001-UP

1шт.

6

714-07-15840

COVER

SN: 60001-UP

2шт.

7

01010-80820

BOLT

SN: 60001-UP

4шт.

8

01643-30823

WASHER

SN: 60001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 60001-UP

2шт.
