Запчасти Komatsu WA380-5 ТРАНСМИССИЯ (1 И 4 МУФТА) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$11

714-12-20004

TRANSMISSION ASS'Y

SN: 62274-UP

1шт.

|$12

714-12-20003

TRANSMISSION ASS'Y

SN: (10320)-00062273

1шт.

|$13

0

TRANSMISSION ASS'Y

SN: ((10320)-(111306))

1шт.

|$14

0

TRANSMISSION ASS'Y

SN: ((10320)-(111258))

1шт.

|$15

714-12-20000

TRANSMISSION ASS'Y

SN: 60001-(10319)

1шт.

|$16

714-12-20014

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 62274-UP

1шт.

|$17

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: (10320)-00062273

1шт.

|$18

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111306))

1шт.

|$19

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: ((10320)-(111258))

1шт.

|$20

714-12-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-(10319)

1шт.

|$21

714-12-20303

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 62274-UP

1шт.

|$22

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-62273

1шт.

|$23

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111306))

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(111258))

1шт.

|$25

714-12-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 62274-UP

1шт.

|$26

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: 60001-62273

1шт.

|$27

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111306))

1шт.

|$28

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCK-UP)

SN: (60001-(111258))

1шт.

|$$20

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$44

714-12-22020

CLUTCH ASS'Y,1ST AND 4TH

SN: 60001-UP

1шт.

1

714-12-22122

SHAFT AND CYLINDER A,1ST AND 4TH

SN: (112192)-UP

1шт.

1

714-12-22121

SHAFT AND CYLINDER A,1ST AND 4TH

SN: 60001-(112191)

1шт.

1

0

SHAFT,UPPER

SN: (112192)-UP

1шт.

1

0

SHAFT,UPPER

SN: 60001-(112191)

1шт.

1

0

HOUSING

SN: (112192)-UP

1шт.

1

0

HOUSING

SN: (110377)-(112191)

1шт.

1

0

HOUSING

SN: 60001-(110376)

1шт.

1

0

ORIFICE

SN: 60001-UP

1шт.

1

0

BALL

SN: 60001-UP

2шт.

2

714-07-22661

PISTON,RANGE

SN: 60001-UP

2шт.

3

714-12-19711

DISC

SN: 60001-UP

12шт.

4

714-16-19730

PLATE,SEPARATE

SN: 60001-UP

14шт.

5

56D-15-12710

SPRING,WAVE

SN: (110524)-UP

12шт.

5

0

SPRING,WAVE

SN: 60001-(110523)

12шт.

6

714-12-12610

PLATE,END

SN: 60001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 60001-UP

2шт.

8

714-16-19220

RING (K1)

SN: 60001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 60001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 60001-UP

3шт.

11

714-08-19560

WASHER

SN: 60001-UP

1шт.

12

714-23-19410

BEARING,NEEDLE

SN: 60001-UP

2шт.

13

714-23-19430

BEARING,NEEDLE

SN: 60001-UP

1шт.

14

714-11-12720

SPACER

SN: 60001-UP

1шт.

15

714-07-22550

SNAP RING

SN: 60001-UP

1шт.

16

714-12-22441

GEAR, 64 TEETH,4TH

SN: 60001-UP

1шт.

17

714-12-22431

GEAR, 26 TEETH,1ST

SN: 60001-UP

1шт.

18

714-12-22511

GEAR, 37 TEETH,2ND

SN: 60001-UP

1шт.

19

714-12-19380

BEARING

SN: 60001-UP

1шт.

20

714-12-39340

BEARING

SN: (112192)-UP

1шт.

20

714-12-29340

BEARING

SN: 60001-(112191)

1шт.

21

419-15-12122

RING (K1)

SN: 60001-UP

3шт.
