Запчасти Komatsu WA380-3MC FIG. A-A БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6741-22-1110

BLOCK ASSEMBLY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6742-01-1360

PLUG, EXPANSION - 1 1/8 IN.

1шт.

3

6742-01-1370

PLUG, EXPANSION - 13/16 IN.

4шт.

4

6742-01-1380

PLUG, EXPANSION

2шт.

5

6736-21-1830

PLUG, EXPANSION

1шт.

6

6742-01-5160

BUSHING, CAMSHAFT

7шт.

7

6741-21-1130

CAP, MAIN BEARING

7шт.

8

6742-01-1420

PLUG, EXPANSION

4шт.

9

6741-21-1140

BOLT - 14-2.00 X 128

14шт.

|$10

6742-01-5159

KIT, LINER

6шт.

10

NSS

LINER, CYLINDER

1шт.

11

6742-01-1520

SEAL, RECTANGULAR RING

1шт.

|$13

6742-01-1440

KIT, CYLINDER BLOCK

1шт.

|$14

6736-21-1810

PLUG, EXPANSION

1шт.

12

6216-94-3450

DRAINCOCK - 1/4 NPT

1шт.

13

6735-21-5530

PLUG, EXPANSION - 1 3/16 IN.

2шт.

14

6732-11-1910

PLUG, PIPE - 1/2 NPT

5шт.

15

6732-11-1920

PLUG, PIPE - 3/4 NPT

2шт.

16

6742-01-1470

DOWEL, PIN

2шт.

17

6732-21-6120

DOWEL, PIN

4шт.

18

6742-01-1480

PLUG, EXPANSION

1шт.

19

6742-01-3890

NOZZLE, PISTON COOLING

12шт.

20

6732-11-1930

PLUG, PIPE

6шт.

21

6742-01-4080

SEAL, O-RING

1шт.

|$25

1296 695 H1

SHIM, COUNTERBORE SERVICE - 0.010 IN. O/S

-2шт.

|$26

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 IN. O/S

-2шт.

|$27

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 IN. O/S

-2шт.

|$28

1296 698 H1

SHIM, COUNTERBORE SERVICE - 0.030 IN. O/S

-2шт.

|$29

1296 699 H1

SHIM, COUNTERBORE SERVICE - 0.040 IN. O/S

-2шт.

|$30

-1шт.

|$31

F1 - INCLUDED IN CYLINDER BLOCK SERVICE KIT.

-1шт.

|$32

-1шт.
