Запчасти Komatsu WA380-3L ДВИГАТЕЛЬ И АКСЕССУАРЫ -

1

423-01-A2000

ENGINE ASSEMBLY

1шт.

2

MOTOR ASSEMBLY, CRANKING (SEE PG 01-008)

-29шт.

|$2

01010-51250

BOLT, MOUNTING CRANKING MOTOR

3шт.

|$3

01643-31232

WASHER

3шт.

|$4

1211 455 H2

GASKET, CRANKING MOTOR

1шт.

|$5

446 839 C2

GASKET, LIQUID - CRANKING MOTOR

1шт.

3

ALTERNATOR (SEE PG 01-014)

-29шт.

4

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

1шт.

|$8

206-01-A1160

SENSOR, ENGINE OIL LEVEL

1шт.

|$9

1209 470 H1

CONNECTOR, MALE

1шт.

|$10

1209 477 H1

SEAL, TERMINAL

4шт.

|$11

1209 466 H1

TERMINAL

4шт.

5

206-01-A1150

SWITCH, ENGINE OIL PRESSURE

1шт.

6

206-01-A1130

SENSOR, ENGINE COOLANT TEMPERATURE

1шт.

|$26

24 466 R1

BUSHING, REDUCER - 3/4 X 1/2 IN

1шт.

7

MUFFLER, EXHAUST (SEE PG 01-022)

-29шт.

8

CLEANER ASSEMBLY, AIR (SEE PG 01-020)

-29шт.

9

1237 733 H1

FAN, BLOWER - ENGINE

1шт.

10

1237 716 H1

SPACER, FAN PILOT

1шт.

|$19

01011-51015

BOLT, FAN MOUNTING

4шт.

|$20

01643-31032

WASHER

4шт.

|$24

-1шт.

|$22

F1 - FOR SERVICE PARTS, SEE SECTION

-1шт.

|$25

-1шт.
