Запчасти Komatsu WA380-3L PROВОЗДУХОВОДЫ GRAPHICS АНГЛ. 9-

|$0

421-93-21310

KIT, SAFETY AND INSTRUCTION

1шт.

1

NSS

SAFETY, RADIATOR CAP

1шт.

2

NSS

SAFETY, BATTERY CABLE

2шт.

3

NSS

INSTRUCTION, ENGINE OIL DRAIN

1шт.

4

NSS

SAFETY, SAFETY BAR

1шт.

5

NSS

SAFETY, KEEP-OUT

2шт.

6

NSS

INSTRUCTION, FUEL

1шт.

7

NSS

INSTRUCTION, RADIATOR DRAIN

1шт.

8

NSS

SAFETY, HYDRAULIC TANK CAP

1шт.

9

NSS

INSTRUCTION, REAR AXLE PIVOT PIN

1шт.

|$10

419-93-A1420

KIT, SAFETY AND INSTRUCTION (INSIDE)

1шт.

10

NSS

INSTRUCTION, WORK EQUIPMENT LEVER LOCK

1шт.

11

NSS

INSTRUCTION, WORK EQUIPMENT LEVER

1шт.

12

NSS

SAFETY, RELAY

1шт.

13

NSS

SAFETY, FUSE

1шт.

14

NSS

SAFETY, WORK EQUIPMENT LEVER LOCK

1шт.

15

NSS

SAFETY, INSPECTION

1шт.

16

NSS

SAFETY, BEFORE OPERATING

1шт.

17

NSS

INSTRUCTION, STARTING SWITCH

1шт.

18

NSS

CAUTION, EMERGENCY PARKING BRAKE

1шт.

19

NSS

OPERATING, EMERGENCY PARKING BRAKE

1шт.

20

NSS

NAME, RELAY

1шт.

21

09805-03000

SAFETY, FULL FENDER

2шт.

22

425-93-A1142

PLATE, I.D

1шт.

|$24

04418-13060

SCREW

2шт.

23

423-93-21230

CHART, OIL

1шт.

24

09690-D0355

MARK, KOMATSU

2шт.

25

417-93-21220

MARK, AVANCE - LOADER

2шт.

26

423-93-11760

MARK, WA380-3

2шт.

27

421-93-21171

MARK, KOMATSU

1шт.

28

421-93-21150

STRIPE, L.H

1шт.

29

421-93-21160

STRIPE, R.H

1шт.

30

09659-53000

CAUTION, ACCUMULATOR

5шт.

31

09960-01001

MARK, LIFT - HERE

4шт.

32

7823-62-9070

KIT, MONITOR PANEL

1шт.

N/I

418-93-11410

CAUTION, EITHER START

1шт.
