Запчасти Komatsu WA380-3L СИДЕНЬЕ ОПЕРАТОРА С ВОЗД. ПОДВЕСКОЙ (KAB) -

|$0

421-57-21510

SEAT, SUSPENSION TYPE

1шт.

|$1

BS162663

UPPER ASSEMBLY, FABRIC

1шт.

1

NSS

FRAME KIT, SEAT

1шт.

2

NSS

COVER, BACK

1шт.

3

NSS

FOAM, BACK

1шт.

4

NSS

COVER, SEAT

1шт.

5

NSS

FOAM, SEAT

1шт.

6

BS163369

HEIGHT RISER ASSEMBLY KIT

1шт.

7

BS163368

LATCH KIT, HEIGHT RISER

1шт.

8

BS162056

SPRING KIT, HEIGHT RISER

1шт.

9

BS164188

HANDLE KIT

1шт.

10

BS162032

ADJUSTMENT KIT, CABLE

1шт.

11

BS157230

SUSPENSION ASSEMBLY

1шт.

12

BS156717

STOP KIT, BUMP / UP

1шт.

13

BS156737

ADJUSTMENT KIT, WEIGHT

1шт.

14

BS156738

BEARING KIT, SUSPENSION

1шт.

15

BS157228

DAMPER KIT

1шт.

16

BS162035

ADJUSTMENT KIT, SLIDERAIL (FORWARD/BACKWARD)

1шт.

17

BS152879

HANDLE, SLIDERAIL

1шт.

18

BS151185

HEADREST KIT

1шт.

19

BS165216

ARMREST KIT, LH

1шт.

|$21

BS166386

ARMREST KIT, RH

1шт.

|$$23

-1шт.

|$23

F1 - ALL KITS HAVE REQUIRED MOUNTING HARDWARE.

-1шт.

|$$25

-1шт.
