Запчасти Komatsu WA380-3 ТРАНСМИССИЯ (1 И 3 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$3

714-12-10011

TORQFLOW ASS'Y

SN: 54001-UP

1шт.

|$4

714-12-10010

TORQFLOW ASS'Y

SN: 53001-54000

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-71A0,

-1шт.

1

714-12-12020

CLUTCH ASS'Y,1ST AND 3RD

SN: 53001-UP

1шт.

1

714-12-12120

SHAFT ASS'Y

SN: 53001-UP

1шт.

2

714-12-12660

PISTON,1ST AND 3RD

SN: 53001-UP

2шт.

3

714-12-19711

DISC

SN: (88845)-UP

12шт.

3

0

DISC

SN: 53001-(88844)

12шт.

4

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

14шт.

5

56D-15-12710

SPRING,WAVE

SN: (190484)-UP

12шт.

5

0

SPRING,WAVE

SN: 53001-(190483)

12шт.

6

714-12-12610

PLATE,END

SN: 53001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 53001-UP

2шт.

8

714-16-19220

RING,SEAL

SN: 53001-UP

2шт.

9

714-16-19210

RING,SEAL

SN: 53001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 53001-UP

3шт.

11

714-08-19560

WASHER,THRUST

SN: 53001-UP

1шт.

12

419-15-12660

BEARING,NEEDLE

SN: 53001-UP

2шт.

13

419-15-13151

BEARING,NEEDLE

SN: (88845)-UP

1шт.

13

0

BEARING,NEEDLE

SN: 53001-(88844)

1шт.

14

714-11-12720

SPACER

SN: 53001-UP

1шт.

15

714-12-12910

SPACER

SN: 53001-UP

1шт.

16

04066-00060

RING,SNAP

SN: 53001-UP

1шт.

17

04066-00062

RING,SNAP

SN: 53001-UP

1шт.

18

714-12-12440

GEAR, 40 TEETH,3RD

SN: 53001-UP

1шт.

19

714-12-12430

GEAR, 21 TEETH,1ST

SN: 53001-UP

1шт.

20

714-12-12510

GEAR, 29 TEETH,2ND

SN: 53001-UP

1шт.

21

06040-06212

BEARING

SN: 53001-UP

1шт.

22

714-12-19340

BEARING,ROLLER

SN: 53001-UP

1шт.

23

419-15-12122

RING,SEAL

SN: 53001-UP

3шт.
