Запчасти Komatsu WA380-3 2-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН(/) [УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ]

|$0

700-92-32001

VALVE ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWEN IN FIG. 6201 TO FIG.6204

Field_1: 16001-

1шт.

|$1

709-90-53200

VALVE ASSEMBLY,RELIEF

Field_1: 16001-

1шт.

1

0

SLEEVE

Field_1: 16001-

1шт.

2

0

VALVE

Field_1: 16001-

1шт.

3

0

PLUG

Field_1: 16001-

1шт.

4

0

SPRING

Field_1: 16001-

1шт.

5

0

SEAT

Field_1: 16001-

1шт.

6

0

O-RING

Field_1: 16001-

1шт.

7

0

RING,BACK UP

Field_1: 16001-

1шт.

8

0

POPPET

Field_1: 16001-

1шт.

9

0

SPACER

Field_1: 16001-

1шт.

10

0

SPRING

Field_1: 16001-

1шт.

11

0

RETAINER

Field_1: 16001-

1шт.

12

0

HOLDER

Field_1: 16001-

1шт.

13

0

NUT

Field_1: 16001-

1шт.

14

0

O-RING

Field_1: 16001-

1шт.

15

0

SCREW

Field_1: 16001-

1шт.

16

0

NUT

Field_1: 16001-

1шт.

17

0

NUT

Field_1: 16001-

1шт.

18

0

WASHER

Field_1: 16001-

2шт.

19

700-93-11320

O-RING

Field_1: 16001-

1шт.

20

700-93-11330

RING,BACK UP

Field_1: 16001-

1шт.

21

07002-13634

O-RING

Field_1: 16001-

1шт.

|$23

709-10-62101

VALVE ASSEMBLY,SUCTION&SAFETY

Field_1: 16001-

1шт.

22

0

SLEEVE

Field_1: 16001-

1шт.

23

0

VALVE

Field_1: 16001-

1шт.

24

0

SEAL

Field_1: 16001-

1шт.

25

0

POPPET

Field_1: 16001-

1шт.

26

0

PISTON

Field_1: 16001-

1шт.

27

0

O-RING

Field_1: 16001-

1шт.

28

0

SEAL

Field_1: 16001-

1шт.

29

0

SPRING

Field_1: 16001-

1шт.

30

0

O-RING

Field_1: 16001-

1шт.

31

0

RING,BACK UP

Field_1: 16001-

1шт.

32

0

NUT

Field_1: 16001-

1шт.

33

0

SPRING

Field_1: 16001-

1шт.

34

07002-13634

O-RING

Field_1: 16001-

1шт.

|$37

709-10-62500

VALVE ASSEMBLY,SUCTION&SAFETY

Field_1: 16001-

1шт.

35

0

SLEEVE

Field_1: 16001-

1шт.

36

0

VALVE

Field_1: 16001-

1шт.

37

0

SEAL

Field_1: 16001-

1шт.

38

0

POPPET

Field_1: 16001-

1шт.

39

0

PISTON

Field_1: 16001-

1шт.

40

0

O-RING

Field_1: 16001-

1шт.

41

0

SEAL

Field_1: 16001-

1шт.

42

0

SPRING

Field_1: 16001-

1шт.

43

0

O-RING

Field_1: 16001-

1шт.

44

0

RING,BACK UP

Field_1: 16001-

1шт.

45

0

NUT

Field_1: 16001-

1шт.

46

0

SPRING

Field_1: 16001-

1шт.

47

07002-13634

O-RING

Field_1: 16001-

1шт.

|$51

700-90-74001

SUCTION VALVE ASSEMBLY

Field_1: 16001-

1шт.

48

0

SLEEVE

Field_1: 16001-

1шт.

49

0

VALVE

Field_1: 16001-

1шт.

50

0

SEAL

Field_1: 16001-

1шт.

51

0

SPRING

Field_1: 16001-

1шт.

52

07002-13634

O-RING

Field_1: 16001-

1шт.
