Запчасти Komatsu WA380-3 2-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН(/) [УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ]

|$0

700-92-32001

VALVE ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWEN IN FIG. 6201 TO FIG.6204

Field_1: 16001-

1шт.

1

0

BODY,VALVE

Field_1: 16001-

1шт.

2

709-91-00080

VALVE SUB ASSEMBLY

Field_1: 16001-

1шт.

3

0

PLUG

Field_1: 16001-

4шт.

4

07002-12434

O-RING

Field_1: 16001-

4шт.

5

0

PLUG

Field_1: 16001-

1шт.

6

07002-13634

O-RING

Field_1: 16001-

1шт.

7

0

FLANGE

Field_1: 16001-

1шт.

8

07000-13035

O-RING

Field_1: 16001-

1шт.

9

01010-81025

BOLT

Field_1: 16001-

2шт.

10

0

SPOOL,DUMP

Field_1: 16001-

1шт.

11

0

SPOOL,LIFT

Field_1: 16001-

1шт.

12

0

RETAINER

Field_1: 16001-

3шт.

13

0

RETAINER

Field_1: 16001-

1шт.

14

0

RETAINER

Field_1: 16001-

2шт.

15

0

SPRING

Field_1: 16001-

2шт.

16

0

RETAINER

Field_1: 16001-

2шт.

17

0

RETAINER

Field_1: 16001-

1шт.

18

0

SPRING

Field_1: 16001-

1шт.

19

0

SPRING

Field_1: 16001-

1шт.

20

0

SPRING

Field_1: 16001-

2шт.

21

0

RETAINER

Field_1: 16001-

1шт.

22

0

RETAINER

Field_1: 16001-

1шт.

23

0

SPRING

Field_1: 16001-

1шт.

24

0

COLLAR

Field_1: 16001-

1шт.

25

0

BOLT

Field_1: 16001-

1шт.

26

0

WASHER

Field_1: 16001-

1шт.

27

0

CASE

Field_1: 16001-

3шт.

28

0

CASE

Field_1: 16001-

1шт.

29

07430-71380

O-RING

Field_1: 16001-

4шт.

30

01252-30820

BOLT

Field_1: 16001-

8шт.

31

0

VALVE

Field_1: 16001-

2шт.

32

0

SPRING

Field_1: 16001-

2шт.

33

0

PLUG

Field_1: 16001-

2шт.

34

07002-13634

O-RING

Field_1: 16001-

2шт.

35

07000-13038

O-RING

Field_1: 16001-

4шт.

36

700-92-11770

BOLT

Field_1: 16001-

2шт.

37

700-81-11222

BOLT

Field_1: 16001-

2шт.

38

01643-31232

WASHER

Field_1: 16001-

4шт.

39

709-90-53200

VALVE ASSEMBLY,RELIEF

Field_1: 16001-

1шт.

40

709-10-62101

VALVE ASSEMBLY,SUCTION&SAFETY

Field_1: 16001-

1шт.

41

709-10-62500

VALVE ASSEMBLY,SUCTION&SAFETY

Field_1: 16001-

1шт.

42

700-90-74001

SUCTION VALVE ASSEMBLY

Field_1: 16001-

1шт.

43

702-21-04170

VALVE ASSEMBLY,PILOT

Field_1: 16001-

1шт.
