Запчасти Komatsu WA380-3 ЗАДН. МОСТ(КОНЕЧНАЯ ПЕРЕДАЧА) [ВЕДУЩ. ВАЛ ДИФФЕРЕНЦ. И КОЛЕСА]

|$0

423-23-20002

AXLE ASS'Y.REAR THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-01A0 TO F4500-04A0

Field_1: 16001-

1шт.

1

423-22-22530

GEAR

Field_1: 16001-

6шт.

2

423-22-22810

BEARING

Field_1: 16001-

12шт.

3

423-22-22510

SHAFT

Field_1: 16001-

6шт.

4

419-22-12570

PIN

Field_1: 16001-

6шт.

5

423-22-22610

CARRIER

Field_1: 16001-

2шт.

6

423-22-22350

WASHER

Field_1: 16001-

2шт.

7

423-22-22540

GEAR

Field_1: 16001-

2шт.

8

419-22-12581

PIN

Field_1: 16001-

8шт.

9

423-22-22410

SHAFT

Field_1: 16001-

2шт.

10

421-22-11860

BEARING

Field_1: 16001-

2шт.

11

423-22-22850

BEARING

Field_1: 16001-

2шт.

12

423-22-22461

SEAL.OIL

Field_1: 16001-

2шт.

13

01011-62420

BOLT

Field_1: 16001-

2шт.

14

423-22-22260

SHIM.0.05mm

Field_1: 16001-

6шт.

|$15

423-22-22270

SHIM.0.2mm

Field_1: 16001-

3шт.

|$16

423-22-22280

SHIM.0.3mm

Field_1: 16001-

3шт.

|$17

423-22-22290

SHIM.0.8mm

Field_1: 16001-

2шт.

15

423-22-22420

SHAFT

Field_1: 16001-

2шт.

16

419-22-12870

BOLT

Field_1: 16001-

36шт.

17

01643-32460

WASHER

Field_1: 16001-

36шт.
