Запчасти Komatsu WA380-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ(/)(НИЖНИЙ КЛАПАН) [ТРАНСМИССИЯ]

|$0

SERIAL NO.

-1шт.

|$1

SERIAL NO.

-1шт.

|$2

714-12-10011

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-71A0

Field_1: 16001-

1шт.

|$3

714-12-17003

VALVE ASS'Y,TRANSMISSION THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0

Field_1: 16001-

1шт.

|$4

714-12-17020

VALVE ASS'Y,LOWER THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN SHOWN IN FIGS.F4350-62A0 AND F4350-63A0

Field_1: 16001-

1шт.

1

0

BODY,LOWER VALVE

Field_1: 16001-

1шт.

2

714-07-16250

VALVE,PRIORITY

Field_1: 16001-

1шт.

3

714-12-16440

VALVE,F-R

Field_1: 16001-

1шт.

4

714-12-16420

VALVE,H-L

Field_1: 16001-

1шт.

5

714-12-16330

VALVE,SPEED

Field_1: 16001-

1шт.

6

714-07-16340

VALVE,BRAKE

Field_1: 16001-

1шт.

7

714-07-16620

SLEEVE

Field_1: 16001-

2шт.

8

02720-10104

PLUG

Field_1: 16001-

2шт.

9

419-15-16631

SPACER

Field_1: 16001-

2шт.

10

714-07-16290

SPRING

Field_1: 16001-

1шт.

11

714-07-16370

SPRING

Field_1: 16001-

2шт.

12

419-15-16620

SPRING

Field_1: 16001-

2шт.

13

714-07-16380

SPRING

Field_1: 16001-

1шт.

14

419-15-15640

PLUG

Field_1: 16001-

3шт.

15

714-07-16842

COVER,LOWER VALVE

Field_1: 16001-

1шт.

16

714-12-15810

COVER,LOWER VALVE

Field_1: 16001-

1шт.

17

714-07-16950

GASKET

Field_1: 16001-

1шт.

18

714-07-16960

GASKET

Field_1: 16001-

1шт.
