Запчасти Komatsu WA380-3 ТРАНСМИССИЯ(ЛЕНИВЕЦ) [ТРАНСМИССИЯ]

|$0

SERIAL NO. IN ( ) INDICATES TRANSMISSION

-1шт.

|$1

714-12-10011

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-71A0

Field_1: 16001-

1шт.

1

714-12-16610

GEAR,34 TEETH,IDLER

Field_1: 16001-

1шт.

2

714-12-19320

BEARING,BALL

Field_1: 16001-

2шт.

3

04064-06020

RING,SNAP

Field_1: 16001-

1шт.

4

421-15-13170

COVER

Field_1: 16001-

1шт.

5

07000-12105

O-RING

Field_1: 16001-

1шт.

6

01010-81230

BOLT

Field_1: 16001-

2шт.

7

01643-31232

WASHER

Field_1: 16001-

2шт.
