Запчасти Komatsu WA380-3 ТРАНСМИССИЯ(1 И 3 МУФТА) [ТРАНСМИССИЯ]

|$0

SERIAL NO. IN ( ) INDICATES TRANSMISSION

-1шт.

|$1

714-12-10011

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-71A0

Field_1: 16001-

1шт.

1

714-12-12020

CLUTCH ASS'Y,1ST AND 3RD

Field_1: 16001-

1шт.

1

714-12-12120

SHAFT ASS'Y

Field_1: 16001-

1шт.

2

714-12-12660

PISTON,1ST AND 3RD

Field_1: 16001-

2шт.

3

714-12-19711

DISC

Field_1: 16001-

12шт.

4

714-16-19730

PLATE,SEPARATE

Field_1: 16001-

14шт.

5

56D-15-12710

SPRING,WAVE

Field_1: 16001-

12шт.

6

714-12-12610

PLATE,END

Field_1: 16001-

2шт.

7

419-15-12140

RING,SNAP

Field_1: 16001-

2шт.

8

714-16-19220

RING,SEAL

Field_1: 16001-

2шт.

9

714-16-19210

RING,SEAL

Field_1: 16001-

2шт.

10

714-08-19570

WASHER,THRUST

Field_1: 16001-

3шт.

11

714-08-19560

WASHER,THRUST

Field_1: 16001-

1шт.

12

714-23-19410

BEARING,NEEDLE

Field_1: 16001-

2шт.

13

714-23-19430

BEARING,NEEDLE

Field_1: 16001-

1шт.

14

714-11-12720

SPACER

Field_1: 16001-

1шт.

15

714-12-12910

SPACER

Field_1: 16001-

1шт.

16

04066-00060

RING,SNAP

Field_1: 16001-

1шт.

17

04066-00062

RING,SNAP

Field_1: 16001-

1шт.

18

714-12-12440

GEAR,49 TEETH,3RD

Field_1: 16001-

1шт.

19

714-12-12430

GEAR,21 TEETH,1ST

Field_1: 16001-

1шт.

20

714-12-12510

GEAR,29 TEETH,2ND

Field_1: 16001-

1шт.

21

714-12-19380

BEARING,

Field_1: 16001-

1шт.

22

714-12-19340

BEARING,ROLLER

Field_1: 16001-

1шт.

23

419-15-12122

RING,SEAL

Field_1: 16001-

3шт.
