Запчасти Komatsu WA380-3 active ГИДРАВЛ-НАСОС ГИДРАВЛИКА

1

423-62-H4110

HYDRAULIC PUMP

SN: 20936

1шт.

1A

423-62-H4120

HYDRAULIC PUMP

SN: 20937-20971

1шт.

2

423-62-H0P01

BOLT KIT

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

1шт.

3

423-62-H0P02

BOLT KIT

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit

1шт.

4

421-62-H0P08

PACKING KIT

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit

1шт.

5

423-62-H0P03

SHAFT SEAL

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit

1шт.

6

423-62-H0P04

REPAIR KIT

EnglischBem: SECTION 1 NOTE: Pos. (6) included in Pos. (1) and (1A) Kit

1шт.

7

423-62-H0P05

REPAIR KIT

EnglischBem: SECTION 2 NOTE: Pos. (7) included in Pos. (1) and (1A) Kit

1шт.

8

423-62-H0P06

REPAIR KIT

EnglischBem: SECTION 3 NOTE: Pos. (8) included in Pos. (1) and (1A) Kit

1шт.

9

423-62-H0P07

REPAIR KIT

EnglischBem: SECTION 4 NOTE: Pos. (9) included in Pos. (1) and (1A) Kit

1шт.

10

423-62-H0P08

THRUST PLATE

EnglischBem: SECTION 1 NOTE: Pos. (10) included in Pos. (1) and (1A) Kit

1шт.

11

423-62-H0P09

THRUST PLATE

EnglischBem: SECTION 1 NOTE: Pos. (11) included in Pos. (1) and (1A) Kit

1шт.
