Запчасти Komatsu WA380-1LC ТОПЛИВН. ТРУБЫ TRIANGULAR ТРУБКА БАЛКА ТОПЛИВН. СИСТЕМА

1

6732-71-6230

SEAL, BANJO CONNECTOR

7шт.

2

6732-71-6240

BOLT, BANJO CONNECTOR

7шт.

3

1240 225 H1

BOLT - M6x14

4шт.

4

6734-71-5530

WASHER, PLAIN

4шт.

5

6734-71-5710

BRACE, TUBE

2шт.

6

6734-71-5720

ISOLATOR, VIBRATION

4шт.

7

1240 769 H1

BRACE, TUBE TRIANGULAR

2шт.

8

1241 038 H1

TUBE, INJECTOR FUEL SUPPLY - NO. 1 CYLINDER

1шт.

9

1241 039 H1

TUBE, INJECTOR FUEL SUPPLY - NO. 2 CYLINDER

1шт.

10

1241 040 H1

TUBE, INJECTOR FUEL SUPPLY - NO. 3 CYLINDER

1шт.

11

6742-01-2260

TUBE, INJECTOR FUEL SUPPLY - NO. 4 CYLINDER

1шт.

12

1241 042 H1

TUBE, INJECTOR FUEL SUPPLY - NO. 5 CYLINDER

1шт.

13

1241 043 H1

TUBE, INJECTOR FUEL SUPPLY - NO. 6 CYLINDER

1шт.

14

1270 368 H92

MANIFOLD, FUEL

1шт.

15

6732-71-2170

CONNECTOR, BANJO

1шт.

|$21

-1шт.

|$16

IN ORDER TO USE THIS MANIFOLD TO SERVICE ENGINES BUILT WITH THE OLD

-1шт.

|$17

MANIFOLDS IT WILL BE NECESSARY TO ALSO INCLUDE:

-1шт.

|$18

6732-71-5690

VALVE, CHECK

1шт.

|$19

6736-71-5820

BOLT, BANJO CONNECTOR

1шт.

|$20

6731-71-5850

WASHER, SEALING

2шт.
