Запчасти Komatsu WA380-1LC БЛОК ЦИЛИНДРОВ SQUARED ОСНОВН. ПОДШИПНИК КРЫШКА БЛОК ЦИЛИНДРОВ

|$0

1294 789 H94

BLOCK ASSY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6742-01-1360

PLUG, EXPANSION

1шт.

3

6742-01-1370

PLUG, EXPANSION

4шт.

4

1296 803 H1

PLUG, EXPANSION

2шт.

5

6736-21-1810

PLUG, EXPANSION

1шт.

6

6742-01-1400

BUSHING, CAMSHAFT

7шт.

7

6742-01-1410

CAP, MAIN BEARING

7шт.

8

6742-01-1420

PLUG, EXPANSION

4шт.

9

6742-01-1430

BOLT - 14x128

14шт.

12

6216-94-3450

DRAINCOCK

1шт.

13

6735-21-5530

PLUG, EXPANSION

2шт.

14

6732-11-1910

PLUG, PIPE

4шт.

15

6732-11-1920

PLUG, PIPE

2шт.

16

6742-01-1460

PLUG, PIPE

1шт.

17

6732-21-6120

DOWEL, PIN

2шт.

18

6742-01-1470

DOWEL, PIN

4шт.

19

6742-01-1480

PLUG, EXPANSION

1шт.

20

6742-01-3890

NOZZLE, PISTON COOLING

12шт.

21

6732-11-1930

PLUG, PIPE

6шт.

|$20

6742-01-1500

KIT, LINER

6шт.

10

NSS

LINER, CYLINDER

1шт.

11

6742-01-1520

SEAL, RECTANGULAR RING

1шт.

|$23

1296 695 H1

SHIM, COUNTERBORE SERVICE - 0.010 INCH OS

-2шт.

|$24

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 INCH OS

-2шт.

|$25

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 INCH OS

-2шт.

|$26

1296 698 H1

SHIM, COUNTERBORE SERVICE - 0.030 INCH OS

-2шт.

|$27

1296 699 H1

SHIM, COUNTERBORE SERVICE - 0.040 INCH OS

-2шт.

|$28

6742-01-1440

KIT, CYLINDER BLOCK

1шт.

|$31

-1шт.

|$30

F1 - INCLUDED IN CYLINDER BLOCK SERVICE KIT 6742-01-1440

-1шт.

|$32

-1шт.
