Запчасти Komatsu WA380-1LC FIG NO. A OPERATORS СИДЕНЬЕ KAB BRAND - BLACK VINYL РАМА, ЧАСТИ КОРПУСА & SUPERSTRUCTURE

|$0

423-57-A2100

SEAT ASSY, SUSPENSION

1шт.

|$1

423-57-A2410

UPPER ASSY

1шт.

1

206-57-A1460

KIT, SEAT FRAME

1шт.

2

423-57-A2420

KIT, BACK COVER

1шт.

3

206-57-A1430

FOAM, BACK

1шт.

4

423-57-A2430

COVER, SEAT

1шт.

5

206-57-A1450

FOAM, SEAT

1шт.

6

206-57-A1570

HEIGHT RISER KIT

1шт.

7

206-57-A1490

LATCH KIT, HEIGHT RISER

1шт.

8

206-57-A1480

SPRING KIT, HEIGHT RISER

1шт.

9

206-57-A1560

HANDLE KIT

1шт.

10

206-57-A1580

COVER KIT, SUSPENSION

1шт.

11

206-57-A1540

ADJUSTMENT KIT, WEIGHT

1шт.

12

206-57-A1550

STOP KIT, BUMPER

1шт.

13

206-57-A1520

SUSPENSION ASSY

1шт.

14

206-57-A1610

BEARING KIT, SUSPENSION

1шт.

15

206-57-A1530

ADJUSTMENT KIT, FORWARD / BACKWARD

1шт.

16

206-57-A1510

DAMPER KIT

1шт.

17

206-57-A1590

SLIDERAIL KIT

1шт.

|$19

206-57-A1620

HEADREST KIT

1шт.

|$20

206-57-A1470

ADJUSTMENT KIT, CABLE

1шт.

|$21

425-57-A1110

RISER, - MOUNT SEAT TO FLOOR

2шт.

|$22

01435-01220

BOLT, MOUNT RISERS TO CAB FLOOR

4шт.

|$$24

-1шт.

|$24

F1 - ALL KITS HAVE REQUIRED MOUNTING HARDWARE.

-1шт.

|$$26

-1шт.
