Запчасти Komatsu WA350-3A-SN ГИДРОТРАНСФОРМАТОР ТРАНСМИССИЯ

|1

714-12-10011

TORQFLOW ASS'Y

SN: 54001-UP

1шт.

|1

714-12-10010

TORQFLOW ASS'Y

SN: 53001-54000

1шт.

|1

714-12-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 54001-UP

1шт.

|1

714-12-10050

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-54000

1шт.

|1

714-12-10020

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 54001-UP

1шт.

|1

714-12-10032

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 53001-54000

1шт.

|$$7

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|1

711-50-00300

TORQUE CONVERTER A.

SN: 53001-UP

1шт.

1

711-50-41120

PUMP

SN: 53001-UP

1шт.

2

711-50-41520

TURBINE

SN: 53001-UP

1шт.

3

711-50-41531

BOSS

SN: 53001-UP

1шт.

4

01010-81025

BOLT

SN: 53001-UP

18шт.

5

01643-31032

WASHER

SN: 53001-UP

18шт.

6

711-50-42111

STATOR

SN: 53001-UP

1шт.

7

01010-80825

BOLT

SN: 53001-UP

24шт.

8

01643-30823

WASHER

SN: 53001-UP

24шт.

9

711-50-42520

SHAFT

SN: 53001-UP

1шт.

10

07018-31104

RING,SEAL

SN: 53001-UP

1шт.

11

04064-07525

RING,SNAP

SN: 53001-UP

1шт.

12

06040-06316

BEARING

SN: 53001-UP

1шт.

13

01010-81060

BOLT

SN: 53001-UP

12шт.

14

01643-31032

WASHER

SN: 53001-UP

12шт.

15

06043-06214

BEARING

SN: 53001-UP

1шт.

16

711-47-11770

PLATE

SN: 53001-UP

1шт.

17

04064-07025

RING,SNAP

SN: 53001-UP

1шт.

18

711-50-41210

CASE

SN: 53001-UP

1шт.

19

711-50-41250

PILOT

SN: 53001-UP

1шт.

20

01010-80825

BOLT

SN: 53001-UP

8шт.

21

01643-30823

WASHER

SN: 53001-UP

8шт.

22

711-50-41140

GEAR

SN: 53001-UP

1шт.
