Запчасти Komatsu WA350-3A-SN МАРКИРОВКА(№8-) МАРКИРОВКА

|1

426-93-21530

PLATE KIT

SN: 54008-UP

1шт.

1

0

PLATE¤ SAFETY,RADIATOR CAP

SN: 54008-UP

1шт.

2

0

PLATE¤ SAFETY,BATTERY CABLE

SN: 54008-UP

2шт.

3

0

PLATE¤ SAFETY,KEEP OUT

SN: 54008-UP

1шт.

4

0

PLATE¤ SAFETY,SAFETY BAR

SN: 54008-UP

1шт.

5

0

PLATE¤ SAFETY,FAN

SN: 54008-UP

2шт.

6

0

PLATE¤ SAFETY,KEEP OUT

SN: 54008-UP

1шт.

7

0

PLATE¤ SAFETY,HYDRAULIC TANK CAP

SN: 54008-UP

1шт.

|8

426-93-21540

PLATE KIT

SN: 54008-UP

1шт.

8

0

PLATE¤ NAME,CYLINDER BOTTOM PIN

SN: 54008-UP

1шт.

9

0

PLATE¤ NAME,REAR AXLE PIVOT PIN

SN: 54008-UP

1шт.

10

0

PLATE¤ INSTRUCTION,FUEL

SN: 54008-UP

1шт.

11

0

PLATE¤ INSTRUCTION,STEERING HOSE

SN: 54008-UP

1шт.

12

0

PLATE¤ NAME,RADIATOR DRAIN

SN: 54008-UP

1шт.

13

0

PLATE¤ NAME,ENGINE OIL DRAIN

SN: 54008-UP

1шт.

14

423-93-21142

CHART¤ OIL

SN: 54001-UP

1шт.

15

421-93-21260

PLATE¤ MARK,ACTIVE LOADER

SN: 54001-UP

2шт.

16

423-93-11750

PLATE¤ MARK,WA350

SN: 53001-UP

2шт.

17

421-93-21150

PLATE¤ STRIPE,L.H.

SN: 53001-UP

1шт.

18

421-93-21160

PLATE¤ STRIPE,R.H.

SN: 53001-UP

1шт.

19

421-93-21171

PLATE¤ MARK,KOMATSU

SN: 53001-UP

1шт.

20

09806-C0882

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 54008-UP

2шт.

21

09807-C0882

PLATE¤ SAFETY,KEEP OUT

SN: 54008-UP

2шт.

22

09960-01001

PLATE¤ MARK,HANDLING

SN: 53001-UP

4шт.

23

421-93-21510

PLATE

SN: 53001-UP

1шт.
