Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-12-10000
TRANSMISSION ASS'Y
SN: 63001-UP
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.
-1шт.
|1
714-12-10041
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 64001-UP
1шт.
|1
714-12-10040
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 63001-64000
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.
-1шт.
1
419-15-14670
ELBOW
SN: 63001-UP
1шт.
3
419-15-14641
ELBOW
SN: 63001-UP
1шт.
5
714-12-18761
PLATE
SN: 63001-UP
1шт.
6
714-12-18450
CLAMP
SN: 63001-UP
1шт.
8
714-12-18210
TUBE
SN: 63001-UP
1шт.
12
419-15-17541
SPACER
SN: 63001-UP
1шт.
16
714-12-18330
FLANGE
SN: 63001-UP
1шт.
20
714-12-18850
ELBOW
SN: 63001-UP
2шт.
23
01010-80855
BOLT
SN: 63001-UP
4шт.
26
07235-10628
ELBOW
SN: 63001-UP
4шт.
29
714-12-18420
HOSE
SN: 63001-UP
1шт.
30
714-13-18750
COVER
SN: (88311)-UP
1шт.
33
42A-16-11210
PLATE
SN: 63001-UP
1шт.
38
714-12-18890
TUBE
SN: 63001-UP
1шт.
Выбрано товаров: 50
