Запчасти Komatsu WA350-3-H КЛАПАН АККУМУЛЯТОРА ТРАНСМИССИИ ТРАНСМИССИЯ

|1

714-12-10000

TRANSMISSION ASS'Y

SN: 63001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

|1

714-12-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-12-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

|1

714-12-15600

VALVE ASS'Y,ACCUMULATOR

SN: 63001-UP

1шт.

1

714-11-15160

BODY

SN: 63001-UP

1шт.

2

714-11-15830

COVER

SN: 63001-UP

1шт.

3

714-11-15260

VALVE

SN: 63001-UP

3шт.

4

714-07-16470

SPRING

SN: 63001-UP

1шт.

5

714-07-16480

SPRING

SN: 63001-UP

2шт.

6

714-15-15470

SPACER

SN: 63001-UP

2шт.

7

714-13-15460

SPACER

SN: 63001-UP

1шт.

8

714-11-15370

STOPPER

SN: 63001-UP

1шт.

9

714-15-15380

STOPPER

SN: 63001-UP

2шт.

10

01252-31025

BOLT

SN: 63001-UP

4шт.

11

07000-03038

O-RING (K2)

SN: 63001-UP

3шт.

12

07000-02014

O-RING (K2)

SN: 63001-UP

1шт.

13

07043-30108

PLUG

SN: 63001-UP

2шт.
