Запчасти Komatsu WA350-3-H КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (КРЕПЛЕНИЕ) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-12-10000

TRANSMISSION ASS'Y

SN: 63001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

|1

714-12-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-12-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

1

714-12-15001

VALVE ASS'Y,TRANSMISSION

SN: 63001-UP

1шт.

2

714-07-16670

BOLT

SN: 63001-UP

4шт.

3

01011-81040

BOLT

SN: 63001-UP

7шт.

4

01011-81045

BOLT

SN: 63001-UP

1шт.

5

01643-31032

WASHER

SN: 63001-UP

1шт.

5A

08036-11214

CLIP

SN: (88404)-UP

1шт.

6

01011-81015

BOLT

SN: (88404)-UP

1шт.

|6

01011-81015

BOLT

SN: 63001-(88403)

2шт.

6A

01011-81025

BOLT

SN: (88404)-UP

1шт.

6B

01643-31032

WASHER

SN: (88404)-UP

3шт.

7

08053-01510

CLIP

SN: 63001-UP

1шт.

8

01010-81085

BOLT

SN: 63001-UP

1шт.

9

426-06-11570

BRACKET

SN: 63001-UP

1шт.

10

01010-81090

BOLT

SN: 63001-UP

1шт.

11

01643-31032

WASHER

SN: 63001-UP

1шт.

12

714-07-16921

GASKET,LOWER VALVE (K2)

SN: (88337)-UP

1шт.

|12

0

GASKET,LOWER VALVE (K2)

SN: 63001-(88336)

1шт.

|13

714-07-16500

VALVE ASS'Y,CHECK

SN: 63001-UP

1шт.

13

714-07-16580

SLEEVE

SN: 63001-UP

1шт.

14

714-07-16570

PLUG

SN: 63001-UP

1шт.

15

714-07-16590

SPRING

SN: 63001-UP

1шт.

16

04260-00635

BALL

SN: 63001-UP

1шт.

17

714-12-15600

VALVE ASS'Y,ACCUMULATOR

SN: 63001-UP

1шт.

18

01010-81080

BOLT

SN: 63001-UP

1шт.

19

01010-81070

BOLT

SN: 63001-UP

2шт.

20

07000-73025

O-RING (K2)

SN: 63001-UP

2шт.

21

07000-72014

O-RING (K2)

SN: 63001-UP

2шт.

22

714-12-15400

VALVE ASS'Y,FLOW CONTROL

SN: 63001-UP

1шт.

23

01252-31065

BOLT

SN: 63001-UP

1шт.

24

01252-31055

BOLT

SN: 63001-UP

3шт.

25

07000-72020

O-RING (K3)

SN: 63001-UP

1шт.
