Запчасти Komatsu WA350-3-H ТРАНСМИССИЯ (2 И 4 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-12-10000

TRANSMISSION ASS'Y

SN: 63001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

|1

714-12-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-12-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-71A1.

-1шт.

|1

714-12-12030

CLUTCH ASS'Y,2ND AND 4TH

SN: 63001-UP

1шт.

1

714-12-12130

SHAFT ASS'Y

SN: 63001-UP

1шт.

2

714-12-12660

PISTON,2ND AND 4TH

SN: 63001-UP

2шт.

3

714-12-19711

DISC

SN: (88646)-UP

12шт.

|3

0

DISC

SN: 63001-(88645)

12шт.

4

714-16-19730

PLATE,SEPARATE

SN: 63001-UP

14шт.

5

419-15-12133

SPRING,WAVE

SN: 63001-UP

12шт.

6

714-12-12610

PLATE,END

SN: 63001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 63001-UP

2шт.

8

714-16-19220

RING,SEAL

SN: 63001-UP

2шт.

9

714-16-19210

RING,SEAL

SN: 63001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 63001-UP

4шт.

11

419-15-13151

BEARING,NEEDLE

SN: (88848)-UP

3шт.

|11

0

BEARING,NEEDLE

SN: 63001-(88847)

3шт.

12

714-12-12460

GEAR¤ 27 TEETH,2ND

SN: 63001-UP

1шт.

13

714-12-12450

GEAR¤ 22 TEETH,4TH

SN: 63001-UP

1шт.

14

714-12-12530

GEAR¤ 27 TEETH

SN: 63001-UP

1шт.

15

714-12-12540

GEAR¤ 31 TEETH

SN: 63001-UP

1шт.

16

06040-06212

BEARING

SN: 63001-UP

1шт.

17

714-12-19350

BEARING,ROLLER

SN: 63001-UP

1шт.

18

714-12-12790

SPACER

SN: 63001-UP

1шт.

19

04066-00065

RING,SNAP

SN: 63001-UP

1шт.

20

04077-00080

RING

SN: 63001-UP

1шт.

21

714-12-12920

SPACER

SN: 63001-UP

1шт.

22

419-15-12122

RING,SEAL

SN: 63001-UP

3шт.
