Запчасти Komatsu WA350-3-H КОВШ (/) КАТАЛОГИ ЗЧ

|$$1

3.8M3 BUCKET

-1шт.

|$$2

4.0M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|1

423-829-2100

BUCKET ASS'Y

SN: 63001-UP

1шт.

1

423-829-2110

BUCKET

SN: 63001-UP

1шт.

2

423-820-2150

PLATE (WELDED)

SN: 63001-UP

2шт.

3

424-70-12220

EDGE (WELDED)

SN: 63001-UP

1шт.

4

423-70-22140

PLATE

SN: 63001-UP

2шт.

5

02090-11475

BOLT

SN: 63001-UP

4шт.

6

02290-11422

NUT

SN: 63001-UP

4шт.

7

01643-32260

WASHER

SN: 63001-UP

4шт.

|$$11

HIGH LIFT BUCKET

-1шт.

|$$12

2.6M3 BUCKET

-1шт.

|$$13

2.8M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|1

423-821-2100

BUCKET ASS'Y

SN: 63001-UP

1шт.

1

423-821-2110

BUCKET

SN: 63001-UP

1шт.

2

423-806-2150

PLATE (WELDED)

SN: 63001-UP

2шт.

3

424-70-12220

EDGE (WELDED)

SN: 63001-UP

1шт.

4

423-70-22140

PLATE

SN: 63001-UP

2шт.

5

02090-11475

BOLT

SN: 63001-UP

4шт.

6

02290-11422

NUT

SN: 63001-UP

4шт.

7

01643-32260

WASHER

SN: 63001-UP

4шт.

|$$22

2.6M3 BUCKET

-1шт.

|$$23

2.8M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|8

423-806-2100

BUCKET ASS'Y

SN: 63001-UP

1шт.

8

423-806-2110

BUCKET

SN: 63001-UP

1шт.

9

424-70-12220

EDGE (WELDED)

SN: 63001-UP

1шт.

10

423-806-2150

PLATE (WELDED)

SN: 63001-UP

2шт.

11

423-806-2310

PLATE (WELDED)

SN: 63001-UP

2шт.

12

423-806-2460

PLATE (WELDED)

SN: 63001-UP

5шт.

13

423-70-22140

PLATE

SN: 63001-UP

2шт.

14

02090-11475

BOLT

SN: 63001-UP

4шт.

15

02290-11422

NUT

SN: 63001-UP

4шт.

16

01643-32260

WASHER

SN: 63001-UP

4шт.

|$$34

3.2M3 BUCKET{LOOSE MATERIAL}

-1шт.

17

423-803-2110

BUCKET¤ 3.1M3

SN: 63001-UP

1шт.

18

424-70-12220

EDGE (WELDED)

SN: 63001-UP

1шт.

19

423-803-2150

PLATE (WELDED)

SN: 63001-UP

2шт.

20

423-803-2310

PLATE (WELDED)

SN: 63001-UP

2шт.

21

423-70-12140

PLATE (WELDED)

SN: 63001-UP

2шт.

|$$40

LIGHT MATERIAL{(FOR COUPLER BUCKET)}

-1шт.

|$$41

2.9M3 BUCKET

-1шт.

22

423-840-2110

BUCKET ASS'Y

SN: 63001-UP

1шт.

23

424-70-12220

EDGE (WELDED)

SN: 63001-UP

1шт.

24

423-70-22150

PLATE (WELDED)

SN: 63001-UP

2шт.
