Запчасти Komatsu WA320PZ-6 MARKS И ТАБЛИЧКИS (ТАБЛИЧКИ) МАРКИРОВКА

1

419-93-42160

PLATE, STRIPE

SN: H00051-UP

2шт.

2

20Y-00-41530

PLATE, SYMBOL, ECOT3

SN: H00051-UP

1шт.

3

419-93-41720

OIL CHART

SN: H00051-UP

1шт.

4

09963-A1640

TAG, DANGER, DO NOT OPERATE

SN: H00051-UP

1шт.

5

424-V07-H050

PLATE, HOOK-SYMBOL

SN: H00051-UP

4шт.

6

42U-93-11A60

MARK, TIE DOWN POINT MARKS

SN: H00051-UP

4шт.

7

09669-0000E

PLATE, SYMBOL, FUEL FILLER

SN: H00051-UP

1шт.

8

09653-A0641

PLATE, WARNING, HIGH TEMPERATURE

SN: H00051-UP

1шт.

9

09161-C0881

PLATE, WARNING, ARTICULATION LOCK

SN: H00051-UP

1шт.

10

09808-A1681

PLATE, WARNING, BATTERY CABLES

SN: H00051-UP

2шт.

11

09806-C1201

PLATE, CAUTION, DO NOT APPROACH

SN: H00051-UP

2шт.

12

09667-A0880

PLATE, CAUTION, ROTATING OBJECT

SN: H00051-UP

2шт.

13

09807-C1201

PLATE, CAUTION, WORK EQUIPMENT FALL DOWN, DO NOT APPROACH

SN: H00051-UP

2шт.

14

09162-C1201

PLATE, DANGER, KEEP OFF

SN: H00051-UP

2шт.

15

09659-A0881

PLATE, SAFETY

SN: H00051-UP

1шт.

16

421-93-H1830

DECAL, LIFT/SECURE

SN: H00051-UP

1шт.

17

421-93-H1390

DECAL, KOMATSU

SN: H00051-UP

1шт.

18

09823-00001

PLATE, MAX. DRAWBAR PULL

SN: H00051-UP

1шт.

19

423-00-H0430

RIVET

SN: H00051-UP

2шт.

20

14X-98-35181

PLATE, REFLECTOR, RED

SN: H00051-UP

2шт.

21

20G-46-K1681

REFLECTOR, YELLOW

SN: H00051-UP

6шт.

22

20E-00-K1270

PLATE, OIL

SN: H00051-UP

1шт.

23

421-93-H2150

DECAL, BATTERY MAIN SWITCH

SN: H00051-UP

1шт.

24

421-93-H2160

DECAL, BATTERY MAIN SWITCH

SN: H00051-UP

1шт.

25

09659-A057B

PLATE, FUEL, WARNING, EXPLOSIVE HAZARD

SN: H00051-UP

2шт.

26

423-93-H1360

DECAL, WATER DRAIN

SN: H00051-UP

1шт.

27

418-93-42540

PLATE

SN: H00051-UP

1шт.

28

423-93-H1370

DECAL, OIL DRAIN

SN: H00051-UP

1шт.

29

09659-A0641

PLATE, WARNING, EXPLOSIVE HAZARD, GAS SPRING

SN: H00051-UP

1шт.

30

09659-A0641

PLATE, WARNING, EXPLOSIVE HAZARD, DOOR,GRILL GAS SPRING

SN: H00051-UP

6шт.
