Запчасти Komatsu WA320PZ-6 МАРКИРОВКА, ПЛАСТИНА (№7-7) МАРКИРОВКА, АНГЛ.

1

09161-23000

Plate, Warning, Articulation Lock

SN: 70452-70535

1шт.

2

09653-03001

Plate, Warning, High Temperature

SN: 70452-70535

1шт.

3

419-U77-4710

Plate,L.H.

SN: 70452-70535

1шт.

4

419-U77-4720

Plate,R.H.

SN: 70452-70535

1шт.

5

419-93-42160

Plate, Stripe

SN: 70452-70535

2шт.

6

419-93-42231

Oil Chart

SN: 70452-70535

1шт.

7

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 70452-70535

4шт.

8

09668-03001

Plate, Warning, Hot Water

SN: 70452-70535

1шт.

8

419-93-22231

Plate

SN: 70452-70535

1шт.

9

Plate, Remote Grease, Rear Axle, Rear Axle

SN: 70452-70535

1шт.

10

Plate, Radiator Drain

SN: 70452-70535

1шт.

11

Plate, Remote Grease, Bucket Cylinder Bottom, Bucket Cylinder Bottom Pin

SN: 70452-70535

1шт.

12

Plate, Remote Grease, Steering Cylinder,R.H.

SN: 70452-70535

1шт.

13

Plate, Remote Grease, Steering Cylinder,L.H.

SN: 70452-70535

1шт.

14

09669-0000E

Plate, Symbol, Fuel Filler

SN: 70452-70535

1шт.

15

418-93-42410

Plate, Stripe, Low Clarrance

SN: 70452-70535

4шт.

16

418-93-43341

Plate, Caution Cleaning Core

SN: 70452-70535

1шт.

17

09690-C0800

Plate, Komatsu Logo

SN: 70452-70535

2шт.

18

20Y-00-41530

Plate, Symbol, Ecot3, Ecot 3

SN: 70452-70535

1шт.

19

418-93-42240

Plate, Prefilter Cation, Caution. Pre Filter

SN: 70452-70535

1шт.

20

09162-23000

Plate, Danger, Keep Off

SN: 70452-70535

2шт.

21

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 70452-70535

2шт.

22

09667-03001

Plate, Caution, Rotating Object

SN: 70452-70535

2шт.

23

09812-13000

Plate, Danger, Keep a Safe Distance

SN: 70452-70535

2шт.

24

09808-03000

Plate, Warning, Battery Cables

SN: 70452-70535

2шт.

25

09963-03001

Tag, Danger, Do Not Operate

SN: 70452-70535

1шт.

26

09659-53000

Plate, Warning, Explosion Hazard

SN: 70452-70535

4шт.

27

14X-98-35181

Plate, Reflector, Reflector

SN: 70452-70535

2шт.
