Запчасти Komatsu WA320PZ-6 HST МОТОР (/7)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

419-18-41300

MOTOR

SN: 70001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A1 TO Y1651-07A1.

-1шт.

|$$3

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

UC4020753403

CONTROL ASS'Y

SN: 70001-UP

1шт.

1

UC1020772287

HOUSING,CONTROL

SN: 70001-UP

1шт.

2

UC1094326623

BUSHING,CONTROL

SN: 70001-UP

1шт.

3

UC1020069563

CONTROL PISTON

SN: 70001-UP

1шт.

4

UC1706511191

SPRING

SN: 70001-UP

1шт.

5

UC1709213395

SPRING

SN: 70001-UP

1шт.

6

UC1709214196

SPRING

SN: 70001-UP

1шт.

7

UC1706511173

SPRING

SN: 70001-UP

1шт.

8

UC1020451292

CONTROL PISTON

SN: 70001-UP

1шт.

9

UC1096501963

BUSHING

SN: 70001-UP

1шт.

10

UC1020450648

SPRING

SN: 70001-UP

1шт.

11

UC1301571008

BOLT,HEXAGON

SN: 70001-UP

4шт.

12

UC1700833817

WASHER

SN: 70001-UP

1шт.

13

UC1302086116

SCREW,HEXAGON

SN: 70001-UP

1шт.

14

UC1700877569

PIN,PARALLEL

SN: 70001-UP

1шт.

15

UC1701524257

NUT,HEXAGON

SN: 70001-UP

1шт.

16

UC1701538687

PLUG

SN: 70001-UP

5шт.

17

UC1300211008

O-RING

SN: 70001-UP

1шт.

18

UC4020757708

SOLENOID

SN: 70001-UP

2шт.
