Запчасти Komatsu WA320PZ-6 HST МОТОР (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

419-18-41200

MOTOR

SN: 70001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 TO Y1651-06A0.

-1шт.

|$4

419-18-41300

MOTOR

SN: 70001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A1 TO Y1651-07A1.

-1шт.

|$$5

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$7

UC4096038857

CYLINDER BLOCK

SN: 70001-UP

1шт.

1

UC1096506894

CYLINDER BLOCK

SN: 70001-UP

1шт.

2

UC1099217899

LENS,CONTROL

SN: 70001-UP

1шт.

3

UC1099216044

PIN,CENTER

SN: 70001-UP

1шт.

4

UC4020366779

PISTON ASS'Y

SN: 70001-UP

7шт.

5

UC1099215775

SHIM

SN: 70001-UP

1шт.

5

UC1099215784

SHIM

SN: 70001-UP

1шт.

5

UC1099215793

SHIM

SN: 70001-UP

1шт.

5

UC1099215803

SHIM

SN: 70001-UP

1шт.

5

UC1099215812

SHIM

SN: 70001-UP

1шт.

5

UC1099215821

SHIM

SN: 70001-UP

1шт.

6

UC1099215839

SPRING

SN: 70001-UP

1шт.

7

UC1020366442

PLATE

SN: 70001-UP

1шт.

8

UC1708311094

SCREW

SN: 70001-UP

14шт.
