Запчасти Komatsu WA320PZ-6 HST МОТОР (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

419-18-41200

MOTOR

SN: 70001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A0 TO Y1651-06A0.

-1шт.

|$4

419-18-41300

MOTOR

SN: 70001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1651-01A1 TO Y1651-07A1.

-1шт.

|$$5

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$7

UC4020725866

ROTARY GROUP

SN: 70001-UP

1шт.

1

UC4096038857

CYLINDER BLOCK

SN: 70001-UP

1шт.

2

0

SHAFT

SN: 70001-UP

1шт.

3

0

SHIM

SN: 70001-UP

1шт.

4

0

PLATE, 3.15MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.2MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.25MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.3MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.35MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.4MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.45MM,BACK-UP

SN: 70001-UP

1шт.

4

0

PLATE, 3.5MM,BACK-UP

SN: 70001-UP

1шт.

5

0

WASHER

SN: 70001-UP

1шт.

6

0

BEARING

SN: 70001-UP

1шт.

7

0

BEARING

SN: 70001-UP

1шт.
