Запчасти Komatsu WA320PZ-6 МАРКИРОВКА (АНГЛ.) (PICTORIAL)(№7-) МАРКИРОВКА

1

09161-C0641

PLATE, SAFETY,FLAME LOCK

SN: 70001-UP

1шт.

2

09653-A0641

PLATE, SAFETY,HIGH TEMPERATURE

SN: 70001-UP

2шт.

3

419-U77-4710

PLATE,MACHINE NAME L.H.

SN: 70001-UP

1шт.

4

419-U77-4720

PLATE,MACHINE NAME R.H.

SN: 70001-UP

1шт.

5

419-93-42160

PLATE,STRIPE

SN: 70001-UP

2шт.

6

419-93-42350

OIL CHART

SN: 70001-UP

1шт.

7

09960-01601

PLATE, MARK,LIFTING EYE

SN: 70001-UP

4шт.

|$9

419-93-22231

PLATE, MARK

SN: 70001-UP

1шт.

8

0

PLATE, MARK,REAR AXLE

SN: 70001-UP

1шт.

9

0

PLATE, MARK,RADIATOR DRAIN

SN: 70001-UP

1шт.

10

0

PLATE, MARK,BUKCKET CYLINDER BOTTOM PIN

SN: 70001-UP

1шт.

11

0

PLATE, MARK,STEERING CYLINDER R.H.

SN: 70001-UP

1шт.

12

0

PLATE, MARK,STEERING CYLINDER L.H.

SN: 70001-UP

1шт.

13

09669-0000E

PLATE, CAUTION,DIESEL FUEL

SN: 70001-UP

1шт.

14

418-93-42410

PLATE,LOW CLARRANCE

SN: 70001-UP

4шт.

15

418-93-43341

PLATE,ROTATION CAUTION

SN: 70001-UP

1шт.

16

09690-C0800

PLATE, MARK,KOMATSU

SN: 70001-UP

2шт.

17

20Y-00-41530

PLATE, MARK,ECOT 3

SN: 70001-UP

1шт.

18

418-93-42240

PLATE,PRE FILTER CAUTION

SN: 70001-UP

1шт.

19

09162-C0641

PLATE, SAFETY,ARTICULATE

SN: 70001-UP

2шт.

20

09807-C0883

PLATE, SAFETY,WORK MACHINE FALL

SN: 70001-UP

2шт.

21

09667-A0880

PLATE, SAFETY,FAN ROTATION CAUTION

SN: 70001-UP

2шт.

22

09808-A1201

PLATE, SAFETY,ELECTRIC SHOCK FROM CABLE

SN: 70001-UP

2шт.

23

09806-C0883

PLATE, SAFETY,APPROACH CAUTION

SN: 70001-UP

2шт.

24

09963-A1640

TAG,CHECK AND SERVICE CAUTION

SN: 70001-UP

1шт.

25

14X-98-35181

PLATE,REFLECTOR

SN: 70001-UP

2шт.

26

09659-A057B

PLATE, SAFETY,ACCUMULATOR

SN: 70001-UP

4шт.
