Запчасти Komatsu WA320PT-5L HST НАСОС (/) ГИДРАВЛИКА

|$1

PUMP,(SEE FIG. H1610-01A0)

SN: A39001-UP

-1шт.

|$2

0

ROTARY GROUP

SN: A39001-UP

1шт.

1

0

CYLINDER BLOCK

SN: A39001-UP

1шт.

2

0

PISTON

SN: A39001-UP

9шт.

3

UC10992172031

SPRING

SN: A39001-UP

1шт.

4

UC17044512261

CRADLE

SN: A39001-UP

1шт.

5

UC17044903491

RING,SLIDE

SN: A39001-UP

1шт.

6

UC17092170761

SHAFT

SN: A39001-UP

1шт.

7

UC17042141821

WIRE

SN: A39001-UP

2шт.

8

0

SHIM

SN: A39001-UP

1шт.

|$11

0

SHIM

SN: A39001-UP

1шт.

|$12

0

SHIM

SN: A39001-UP

1шт.

|$13

0

SHIM

SN: A39001-UP

1шт.

9

0

PLATE,RETAINING

SN: A39001-UP

1шт.

10

0

BALL,RETAINING

SN: A39001-UP

1шт.

11

UC10206659411

BEARING,LINER

SN: A39001-UP

1шт.

12

UC10992171751

WASHER

SN: A39001-UP

2шт.

13

UC17043546571

SPRING,PRESSURE

SN: A39001-UP

1шт.

14

UC17015626991

BEARING,ROLLER

SN: A39001-UP

1шт.

15

UC17083057871

BEARING ASS'Y

SN: A39001-UP

1шт.

16

UC17008441651

RING,RETAINING

SN: A39001-UP

1шт.

17

UC10260000291

RING,RETAINING

SN: A39001-UP

2шт.

18

UC17083098081

SEAL RING,SHAFT

SN: A39001-UP

1шт.

19

UC17008340581

RING,RETAINING

SN: A39001-UP

1шт.
