Запчасти Komatsu WA320 AVANCE CUSTOM ПЕРЕДНИЙ МОСТ ДИФФЕРЕНЦ. [ТРАНСМИССИЯ]

|$1

419-22-20001

AXLE ASS'Y,FRONT

Field_2: 20001-

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS. F4400-01A0 TO F4400-04A0

-1шт.

1

419-22-23112

HOUSING

Field_2: 20001-

1шт.

2

07043-70211

PLUG

Field_2: 20001-

2шт.

3

07044-13620

PLUGЃCDRAIN

Field_2: 20001-

1шт.

4

07002-13634

O-RING

Field_2: 20001-

1шт.

5

07040-12012

PLUG

Field_2: 20001-

2шт.

6

07002-12034

O-RING. (FOR SHIPPING)

Field_2: 20001-

2шт.

7

04020-01228

PIN,DOWNEL

Field_2: 20001-

4шт.

|$10

419-22-21200

PINION ASS'Y,GEAR

Field_2: 20001-

1шт.

8

419-22-21210

PINION

Field_2: 20001-

1шт.

9

419-22-21220

GEAR,BEVEL

Field_2: 20001-

1шт.

10

419-22-21130

CAGE

Field_2: 20001-

1шт.

11

419-22-11810

BEARING

Field_2: 20001-

1шт.

12

419-22-11860

SPACER

Field_2: 20001-

1шт.

13

419-22-11820

BEARING

Field_2: 20001-

1шт.

14

418-22-21330

SEAL,OIL

Field_2: 20001-

1шт.

15

418-22-21310

PROTECTOR

Field_2: 20001-

1шт.

16

419-22-21230

COUPLING

Field_2: 20001-

1шт.

17

423-22-11240

HOLDER

Field_2: 20001-

1шт.

18

07000-13042

O-RING

Field_2: 20001-

1шт.

19

01011-61615

BOLT

Field_2: 20001-

1шт.

20

07000-15190

O-RING

Field_2: 20001-

1шт.

21

419-22-21360

SHIM, 0.05 MM

Field_2: 20001-

3шт.

|$25

419-22-21370

SHIM, 0.2 MM

Field_2: 20001-

2шт.

|$26

419-22-21380

SHIM, 0.3MM

Field_2: 20001-

2шт.

|$27

419-22-21390

SHIM, 0.8MM

Field_2: 20001-

1шт.

22

01010-61440

BOLT

Field_2: 20001-

10шт.

23

01643-31445

WASHER

Field_2: 20001-

10шт.

|$30

419-22-21500

CASE ASS'Y

Field_2: 20001-

1шт.

24

419-22-21510

CASE

Field_2: 20001-

1шт.

25

419-22-21520

CASE

Field_2: 20001-

1шт.

26

01010-61295

BOLT

Field_2: 20001-

12шт.

27

01643-31232

WASHER

Field_2: 20001-

12шт.

28

175-21-12180

PIN

Field_2: 20001-

4шт.

29

419-22-11432

GEAR. SIDE

Field_2: 20001-

2шт.

30

419-22-11631

WASHER

Field_2: 20001-

2шт.

31

419-22-11421

PINION

Field_2: 20001-

4шт.

32

419-22-11651

WASHER

Field_2: 20001-

4шт.

33

419-22-11412

SHAFT

Field_2: 20001-

1шт.

34

01010-61240

BOLT

Field_2: 20001-

20шт.

35

01643-31232

WASHER

Field_2: 20001-

20шт.

36

419-22-21160

CARRIER

Field_2: 20001-

2шт.

37

419-22-11850

BEARING

Field_2: 20001-

2шт.

38

419-33-11430

RING

Field_2: 20001-

2шт.

39

419-22-21460

SHIM, 0.05 MM

Field_2: 20001-

6шт.

|$47

419-22-21470

SHIM, 0.2 MM

Field_2: 20001-

3шт.

|$48

419-22-21480

SHIM,0.3MM

Field_2: 20001-

3шт.

|$49

419-22-21490

SHIM,0.8MM

Field_2: 20001-

2шт.

40

01010-61240

BOLT

Field_2: 20001-

16шт.

41

01643-31232

WASHER

Field_2: 20001-

16шт.

42

419-22-23120

COVER

Field_2: 20001-

1шт.

43

04020-01228

PIN,DOWEL

Field_2: 20001-

2шт.

44

01010-61240

BOLT

Field_2: 20001-

20шт.

45

01643-31232

WASHER

Field_2: 20001-

20шт.
