Запчасти Komatsu WA320 AVANCE CUSTOM КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ(/) НИЖН. КЛАПАН [ТРАНСМИССИЯ]

|$1

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

-1шт.

|$1

-1шт.

|$3

714-16-20001

TRANSMISSION ASS'Y

Field_2: 20031-

1шт.

|$4

714-16-20000

TRANSMISSION ASS'Y

Field_2: 20001-20030

1шт.

|$1

-1шт.

|$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

-1шт.

|$1

-1шт.

|$8

714-16-25030

CONTROL VALVE ASS'Y

Field_2: 20001-

1шт.

|$1

-1шт.

|$10

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0A

-1шт.

|$1

-1шт.

|$12

714-11-16200

VALVE ASS'Y,LOWER

Field_2: 20001-

1шт.

1

419-15-16521

BODY,LOWER

Field_2: 20001-

1шт.

2

419-15-16530

COVER

Field_2: 20001-

1шт.

3

419-15-16541

GASKET

Field_2: 20001-

1шт.

4

419-15-16551

GASKET

Field_2: 20001-

1шт.

5

419-15-16560

VALVE,T/C REGULATOR SELECTOR

Field_2: 20001-

1шт.

6

714-11-15210

VALVE,FORWARD AND REVERSE SELECTOR

Field_2: 20001-

1шт.

7

714-11-15230

VALVE,H-L SELECTOR

Field_2: 20001-

1шт.

8

714-11-15220

VALVE,SPEED SELECTOR

Field_2: 20001-

1шт.

9

419-15-16610

SPRING,T/C REGULATOR SELECTOR

Field_2: 20001-

1шт.

10

419-15-16620

SPRING,RETURN

Field_2: 20001-

2шт.

11

419-15-16631

SPACER,SPRING

Field_2: 20001-

2шт.

12

02720-10104

PLUG

Field_2: 20001-

1шт.

13

419-15-16640

RETAINER,SPRING

Field_2: 20001-

1шт.

14

419-15-16650

SHIM,1.0MM 1.0MM

Field_2: 20001-

5шт.

15

417-15-17191

SLEEVE

Field_2: 20001-

2шт.

16

417-15-17280

SPRING

Field_2: 20001-

2шт.

17

07042-30108

PLUG

Field_2: 20001-

1шт.

18

01010-31030

BOLT

Field_2: 20001-

2шт.

19

01010-31055

BOLT

Field_2: 20001-

7шт.

20

419-15-15640

PLUG

Field_2: 20001-

1шт.

21

415-15-15430

PLUG

Field_2: 20001-

1шт.
