Запчасти Komatsu WA320 AVANCE CUSTOM ТРАНСМИССИЯ RD И 4 МУФТА [ТРАНСМИССИЯ]

|$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$1

-1шт.

|$3

714-16-20001

TRANSMISSION ASS'Y

Field_2: 20031-

1шт.

|$4

714-16-20000

TRANSMISSION ASS'Y

Field_2: 20001-20030

1шт.

|$1

-1шт.

|$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

-1шт.

|$1

-1шт.

|$8

714-16-22030

CLUTCH ASS'Y,2ND AND 4TH

Field_2: 20001-

1шт.

|$9

714-16-22130

SHAFT ASS'Y

Field_2: 20001-

1шт.

1

0

SHAFT

Field_2: 20001-

1шт.

2

419-15-12750

ORIFICE

Field_2: 20001-

1шт.

3

0

HOUSING ASS'Y

Field_2: 20001-

1шт.

4

714-16-22670

PISTON,2ND AND 4TH

Field_2: 20001-

2шт.

5

714-12-19711

DISC

Field_2: 20001-

10шт.

6

714-16-19730

PLATE,SEPARATE

Field_2: 20001-

12шт.

7

419-15-12133

SPRING,WAVE

Field_2: 20001-

10шт.

8

714-12-12610

PLATE ,END

Field_2: 20001-

2шт.

9

419-15-12140

RING,SNAP

Field_2: 20001-

2шт.

10

714-16-19220

RING,SEAL

Field_2: 20001-

2шт.

11

714-16-19210

RING,SEAL

Field_2: 20001-

2шт.

12

714-08-19570

WASHER,THRUST

Field_2: 20001-

3шт.

13

714-11-19510

WASHER,THRUST

Field_2: 20001-

1шт.

14

419-15-12270

BEARING,NEEDLE

Field_2: 20001-

1шт.

15

419-15-12660

BEARING,NEEDLE

Field_2: 20001-

1шт.

16

419-15-13151

BEARING,NEEDLE

Field_2: 20001-

1шт.

17

714-16-22460

GEARЃA42 TEETH,2ND

Field_2: 20001-

1шт.

18

714-16-22450

GEARЃA22 TEETH,4TH

Field_2: 20001-

1шт.

19

714-16-22530

GEARЃA27 TEETH,OUTPUT

Field_2: 20001-

1шт.

20

714-12-12520

GEARЃA31 TEETH,3RD

Field_2: 20001-

1шт.

21

714-13-19310

BEARING

Field_2: 20001-

1шт.

22

714-13-19320

BEARING

Field_2: 20001-

1шт.

23

714-12-19520

RING,SNAP

Field_2: 20001-

1шт.

24

419-15-12122

RING,SEAL

Field_2: 20001-

3шт.
