Запчасти Komatsu WA320 AVANCE CUSTOM ТРАНСМИССИЯ 1 И 3 МУФТА [ТРАНСМИССИЯ]

|$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$1

-1шт.

|$3

714-16-20001

TRANSMISSION ASS'Y

Field_2: 20031-

1шт.

|$4

714-16-20000

TRANSMISSION ASS'Y

Field_2: 20001-20030

1шт.

|$1

-1шт.

|$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

-1шт.

|$1

-1шт.

|$8

714-16-22020

CLUTCH ASS'Y,1ST AND 3RD

Field_2: 20001-

1шт.

|$9

714-16-22120

SHAFT ASS'Y

Field_2: 20001-

1шт.

1

714-16-22220

SHAFT

Field_2: 20001-

1шт.

2

714-16-12560

HOUSING ASS'Y

Field_2: 20001-

1шт.

3

714-16-22660

PISTON,1ST AND 3RD

Field_2: 20001-

2шт.

4

714-12-19711

DISC

Field_2: 20001-

10шт.

5

714-16-19730

PLATE,SEPARATE

Field_2: 20001-

12шт.

6

419-15-12133

SPRING,WAVE

Field_2: 20001-

10шт.

7

714-12-12610

PLATE ,END

Field_2: 20001-

2шт.

8

419-15-12140

RING,SNAP

Field_2: 20001-

2шт.

9

714-16-19230

RING,SEAL

Field_2: 20001-

2шт.

10

714-16-19210

RING,SEAL

Field_2: 20001-

2шт.

11

714-08-19570

WASHER,THRUST

Field_2: 20001-

2шт.

12

714-08-19560

WASHER,THRUST

Field_2: 20001-

2шт.

13

419-15-12660

BEARING,NEEDLE

Field_2: 20001-

3шт.

14

714-12-12740

SPACER

Field_2: 20001-

1шт.

15

714-12-12720

SPACER

Field_2: 20001-

1шт.

16

714-12-19510

RING,SNAP

Field_2: 20001-

1шт.

17

714-16-22440

GEARЃA40 TEETH,3RD

Field_2: 20001-

1шт.

18

714-16-22430

GEARЃA21 TEETH,1ST

Field_2: 20001-

1шт.

19

714-16-22510

GEARЃA29 TEETH

Field_2: 20001-

1шт.

20

714-16-29340

BEARING

Field_2: 20001-

1шт.

21

714-12-19330

BEARING BALL

Field_2: 20001-

1шт.

22

419-15-12122

RING,SEAL

Field_2: 20001-

3шт.
