Запчасти Komatsu WA320-7 U- МАРКИРОВКА ШАССИ ТАБЛИЧКИS МАРКИРОВКА

1

09690-P1000

KOMATSU LOGO

2шт.

2

419-U77-5710

MACHINE MODEL

1шт.

3

419-U77-5720

MACHINE MODEL

1шт.

4

419-93-51720

LUBRICATION CHART

1шт.

5

09693-00450

KOMATSU LOGO

2шт.

|$5

425-93-41710

DECAL PACKAGE

1шт.

6

09960-01601

LIFT POINT AND TIE DOWN POINT MARKS

4шт.

|$7

419-93-52510

DECAL PACKAGE

1шт.

7

09652-31241

CAUTION, DIESEL FUEL

1шт.

8

09161-23000

WARNING, ARTICULATION LOCK

1шт.

9

09162-23000

DANGER, KEEP OFF

2шт.

10

09812-13000

DANGER, KEEP A SAFE DISTANCE

2шт.

11

09808-03000

WARNING, BATTERY CABLES

2шт.

12

09642-13000

SERVICE INSTRUCTION, ENGINE COOLANT AF-NAC

1шт.

13

09697-00001

BATTERY DISCONNECT SWITCH

1шт.

14

418-93-43341

CAUTION CLEANING CORE

1шт.

15

418-93-42240

PRE-FILTER CAUTION

1шт.

16

09664-30012

DANGER, BATTERY

2шт.

|$18

419-93-52520

DECAL PACKAGE

1шт.

17

09653-03001

WARNING, HIGH TEMPERATURE

1шт.

18

09668-03001

WARNING, HOT WATER

1шт.

19

09667-03001

CAUTION, ROTATING OBJECT

2шт.

20

418-93-42410

STRIPE

4шт.

21

421-93-A1510

DO NOT USE ETHER

1шт.

22

09807-C0883

DANGER, KEEP OUT UNDER WORK EQUIPMENT

2шт.

|$25

419-93-22231

DECAL PACKAGE

1шт.

23

REMOTE GRESE (REAR AXEL)

1шт.

24

RADIATOR DRAIN

1шт.

25

REMOTE GREASE (BUCKET CYLINDER BOTTOM)

1шт.

26

REMOTE GREASE (STEERING CYLINDER L.H.)

1шт.

27

REMOTE GREASE (STEERING CYLINDER L.H.)

1шт.

28

09659-53000

WARNING, EXPLOSION HAZARD

1шт.

29

09659-53000

WARNING, EXPLOSION HAZARD

3шт.

30

09659-53000

WARNING, EXPLOSION HAZARD

1шт.

31

09963-03001

TAG, DANGER, DO NOT OPERATE

1шт.

32

14X-98-35181

REFLECTOR

2шт.
