Запчасти Komatsu WA320-7 КАБИНА ROPS, ПОЛ, ПРОВОДКА (№8-) КАБИНА ROPS

1

419-06-55114

Wiring Harness

SN: 80148-UP

1шт.

1

419-06-55113

Wiring Harness

SN: 80001-80147

1шт.

2

08044-11500

Fuse Box Kit

SN: 80001-UP

2шт.

3

08044-00010

Terminal

SN: 80001-UP

36шт.

4

418-06-35210

Connector, 3Amp.

SN: 80001-UP

6шт.

5

HM6440-0014

F-Connector, Blue

SN: 80001-UP

3шт.

5

HM6440-0073

M-Connector, Blue

SN: 80001-UP

3шт.

6

HM6440-0016

F-Connector, Orange

SN: 80001-UP

5шт.

6

HM6440-0075

M-Connector, Orange

SN: 80001-UP

5шт.

7

HM6440-0129

F-Connector, Pink

SN: 80001-UP

5шт.

7

HM6440-0128

M-Connector, Pink

SN: 80001-UP

5шт.

8

HM6440-0081

F-Connector, Gray

SN: 80001-UP

2шт.

8

HM6440-0255

M-Connector, Gray

SN: 80001-UP

2шт.

9

HM6440-0012

F-Connector, Black

SN: 80001-UP

3шт.

9

HM6440-0071

M-Connector, Black

SN: 80001-UP

3шт.

10

HM6440-0136

F-Connector, Purple

SN: 80001-UP

1шт.

10

HM6440-0135

M-Connector, Purple

SN: 80001-UP

1шт.

11

423-06-55170

Wiring Harness

SN: 80001-UP

1шт.

12

7861-94-4001

Resistor

SN: 80001-UP

1шт.

13

419-06-55531

Wiring Harness

SN: 80001-UP

1шт.
