Запчасти Komatsu WA320-6 MARKS И ТАБЛИЧКИS, ТАБЛИЧКИ MARKS И ТАБЛИЧКИS

1

419-93-42160

Plate, Stripe

SN: H62051-UP

2шт.

2

20Y-00-41530

Plate, Symbol, Ecot3

SN: H62051-UP

1шт.

3

419-93-41720

Oil Chart

SN: H62051-UP

1шт.

4

09963-A1640

Tag, Danger, Do Not Operate

SN: H62051-UP

1шт.

5

424-V07-H050

Plate, Hook-Symbol

SN: H62051-UP

4шт.

6

42U-93-11A60

Mark, Tie Down Point Marks

SN: H62051-UP

4шт.

7

09669-0000E

Plate, Symbol, Fuel Filler

SN: H62051-UP

1шт.

8

09653-A0641

Plate, Warning, High Temperature

SN: H62051-UP

1шт.

9

09161-C0881

Plate, Warning, Articulation Lock

SN: H62051-UP

1шт.

10

09808-A1681

Plate, Warning, Battery Cables

SN: H62051-UP

2шт.

11

09806-C1201

Plate, Caution, Do Not Approach

SN: H62051-UP

2шт.

12

09667-A0880

Plate, Caution, Rotating Object

SN: H62051-UP

2шт.

13

09807-C1201

Plate, Caution, Work Equipment Fall Down, Do Not Approach

SN: H62051-UP

2шт.

14

09162-C1201

Plate, Danger, Keep Off

SN: H62051-UP

2шт.

15

09659-A0881

Plate, Safety

SN: H62051-UP

1шт.

16

421-93-H1830

Decal, Lift/Secure

SN: H62051-UP

1шт.

17

421-93-H1390

Decal, KOMATSU

SN: H62051-UP

1шт.

18

09823-00001

Plate, Max. Drawbar Pull

SN: H62051-UP

1шт.

19

423-00-H0430

Rivet

SN: H62051-UP

2шт.

20

14X-98-35181

Plate, Reflector, Red

SN: H62051-UP

2шт.

21

20G-46-K1681

Reflector, Yellow

SN: H62051-UP

6шт.

22

20E-00-K1270

Plate, Oil

SN: H62051-UP

1шт.

23

421-93-H2150

Decal, Battery Main Switch

SN: H62051-UP

1шт.

24

421-93-H2160

Decal, Battery Main Switch

SN: H62051-UP

1шт.

25

09659-A057B

Plate, Fuel, Warning, Explosive Hazard

SN: H62051-UP

2шт.

26

423-93-H1360

Decal, Water Drain

SN: H62051-UP

1шт.

27

418-93-42540

Plate

SN: H62051-UP

1шт.

28

423-93-H1370

Decal, Oil Drain

SN: H62051-UP

1шт.

29

09659-A0641

Plate, Warning, Explosive Hazard, Gas Spring

SN: H62051-UP

1шт.

30

09659-A0641

Plate, Warning, Explosive Hazard, Door,Grill Gas Spring

SN: H62051-UP

6шт.
