Запчасти Komatsu WA320-6 CENTRAL СМАЗКА СИСТЕМА, ПЕРЕДН. РАМА, ФИДЕР (/) CENTRAL СМАЗКА СИСТЕМА

1

416-09-H2280

Bolt

SN: H62051-UP

1шт.

2

421-09-H4800

Bolt

SN: H62051-UP

1шт.

3

01640-20610

Washer

SN: H62051-UP

2шт.

4

419-09-H2860

Screw Locking Device

SN: H62051-UP

2шт.

5

419-09-H2840

Washer

SN: H62051-UP

2шт.

6

42W-09-H4430

Clip

SN: H62051-UP

1шт.

7

419-S95-H520

Block

SN: H62051-UP

1шт.

8

42W-09-H2940

Safety Cap

SN: H62051-UP

10шт.

9

42W-09-H0P06

Hose, 5M

SN: H62051-UP

-26шт.

|$10

42W-09-H0P07

Hose, 10M

SN: H62051-UP

-26шт.

|$11

42W-09-H0P08

Hose, 25M

SN: H62051-UP

-26шт.

10

42W-09-H0P00

Hose, 5M

SN: H62051-UP

-26шт.

|$13

42W-09-H0P01

Hose, 10M

SN: H62051-UP

-26шт.

|$14

42W-09-H0P02

Hose, 25M

SN: H62051-UP

-26шт.

11

42T-09-H3810

Tube

SN: H62051-UP

4шт.

12

425-09-H0260

Tube

SN: H62051-UP

2шт.

13

423-00-H1920

Bushing

SN: H62051-UP

6шт.

14

42W-09-H0P09

Coil, 5M

SN: H62051-UP

-26шт.

15

42W-09-H0P11

Hose Protector, 10M, 10mm

SN: H62051-UP

-26шт.

16

42W-09-H0P12

Hose Protector, 10M, 16mm

SN: H62051-UP

-26шт.
