Запчасти Komatsu WA320-6 CENTRAL СМАЗКА СИСТЕМА, ПЕРЕДН. РАМА, ФИДЕР (/) CENTRAL СМАЗКА СИСТЕМА

|$1

419-S95-H910

Feeder Assembly

SN: H62051-UP

1шт.

1

419-09-H2680

Feeder Front Frame

SN: H62051-UP

1шт.

2

42W-09-H4650

Valve

SN: H62051-UP

5шт.

3

421-09-H4520

Union

SN: H62051-UP

1шт.

4

421-09-H3870

Lubrication Nipple

SN: H62051-UP

1шт.

5

42W-09-H3350

Cap

SN: H62051-UP

1шт.

6

419-09-H2780

Union

SN: H62051-UP

1шт.

7

42W-09-H2940

Safety Cap

SN: H62051-UP

6шт.

8

419-09-H2860

Screw Locking Device

SN: H62051-UP

2шт.

9

416-09-H2280

Bolt

SN: H62051-UP

2шт.

10

419-09-H2840

Washer

SN: H62051-UP

1шт.

11

42W-09-H0P00

Hose, 5M

SN: H62051-UP

-26шт.

|$13

42W-09-H0P01

Hose, 10M

SN: H62051-UP

-26шт.

|$14

42W-09-H0P02

Hose, 25M

SN: H62051-UP

-26шт.

12

42W-09-H0P11

Hose Protector, 10M, 10mm

SN: H62051-UP

-26шт.

|$16

42W-09-H0P12

Hose Protector, 10M, 16mm

SN: H62051-UP

-26шт.

13

42W-09-H0P09

Coil, 5M

SN: H62051-UP

-26шт.

14

423-00-H1920

Bushing

SN: H62051-UP

12шт.

15

42T-09-H3810

Tube

SN: H62051-UP

7шт.

16

423-00-H0P12

Tube, 90°

SN: H62051-UP

2шт.

17

42T-09-H4090

Tube, 45°

SN: H62051-UP

3шт.
