Запчасти Komatsu WA320-6 K-A УПРАВЛЕНИЕ ПОГРУЗКОЙS PPC ПАТРУБКИ ( РЫЧАГИ) OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

419-43-38130

HOSE, 395 MM, RED-YELLOW

SN: A35001--UP

1шт.

2

02782-10315

ELBOW

SN: A35001--UP

1шт.

3

02896-11009

O-RING

SN: A35001--UP

1шт.

4

07002-12034

O-RING

SN: A35001--UP

1шт.

5

02781-00315

UNION

SN: A35001--UP

1шт.

6

07002-12034

O-RING

SN: A35001--UP

1шт.

7

02896-11009

O-RING

SN: A35001--UP

1шт.

8

419-877-3540

HOSE, RED-BLUE

SN: A35001--UP

1шт.

9

702-16-53240

PLUG

SN: A35001--UP

1шт.

10

07000-12018

O-RING

SN: A35001--UP

2шт.

11

419-U77-3671

TEE

SN: A35001--UP

1шт.

12

02896-11009

O-RING

SN: A35001--UP

2шт.

13

02896-11008

O-RING

SN: A35001--UP

1шт.

14

419-U77-3510

HOSE, 185 MM, RED-BLUE

SN: A35001--UP

1шт.

15

418-43-38440

HOSE, 240 MM, RED-YELLOW

SN: A35001--UP

1шт.

16

419-43-38340

HOSE, 310 MM, RED

SN: A35001--UP

1шт.

17

419-43-38350

HOSE, 300 MM, BLUE

SN: A35001--UP

1шт.

18

419-43-38360

HOSE, 310 MM, YELLOW

SN: A35001--UP

1шт.

19

419-43-38370

HOSE, 300 MM, ORANGE

SN: A35001--UP

1шт.

20

20Y-62-16170

BOLT, EYE

SN: A35001--UP

1шт.

21

07000-12015

O-RING

SN: A35001--UP

2шт.

22

419-877-3560

HOSE, 395 MM, BLUE-BLACK

SN: A35001--UP

1шт.

23

419-U77-3592

TEE

SN: A35001--UP

1шт.

24

02896-11009

O-RING

SN: A35001--UP

2шт.

25

02896-11008

O-RING

SN: A35001--UP

1шт.

26

419-U77-3540

HOSE, 290 MM, BLUE-BLACK

SN: A35001--UP

1шт.

27

418-43-38460

HOSE, 490 MM, BLUE-BLACK

SN: A35001--UP

1шт.

28

419-877-3510

HOSE, 425 MM, GREEN

SN: A35001--UP

1шт.

29

419-877-3520

HOSE, 435 MM, WHITE-RED

SN: A35001--UP

1шт.

30

01583-11408

NUT

SN: A35001--UP

8шт.

31

01643-31445

WASHER

SN: A35001--UP

16шт.

32

07000-12011

O-RING

SN: A35001--UP

2шт.

33

01010-81220

BOLT

SN: A35001--UP

2шт.

34

01643-31232

WASHER

SN: A35001--UP

2шт.
