Запчасти Komatsu WA320-6 H-A ОСНОВН. ГИДР. НАСОС. COMPLETE ASSEMBLY (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY ( SEE FIG. H0210-02A0 )

SN: A35001--UP

-1шт.

|$1

705-38-30060

PUMP ASSEMBLY (SAR32)

SN: A35001--UP

1шт.

1

705-19-02551

BRACKET

SN: A35001--UP

1шт.

|$3

705-17-02353

BUSHING, PLANE

SN: A35001--UP

2шт.

2

705-17-30012

CASE, GEAR

SN: A35001--UP

1шт.

3

705-17-02221

CARRIER

SN: A35001--UP

1шт.

|$6

705-17-02353

BUSHING, PLANE

SN: A35001--UP

2шт.

4

04020-01024

PIN, DOWEL

SN: A35001--UP

4шт.

5

04020-01228

PIN, DOWEL

SN: A35001--UP

2шт.

6

705-17-02360

O-RING

SN: A35001--UP

2шт.

7

705-19-30760

GEAR, DRIVE

SN: A35001--UP

1шт.

8

705-17-30512

GEAR, DRIVEN

SN: A35001--UP

1шт.

9

705-17-02612

PLATE, SIDE

SN: A35001--UP

2шт.

10

705-17-02430

RING, BACK-UP

SN: A35001--UP

2шт.

11

705-17-02460

RING

SN: A35001--UP

2шт.

12

01253-61200

BOLT

SN: A35001--UP

4шт.

13

01643-51232

WASHER

SN: A35001--UP

4шт.

14

705-17-02330

COUPLING ASSEMBLY

SN: A35001--UP

1шт.

15

705-17-03381

O-RING

SN: A35001--UP

1шт.

16

01252-61450

BOLT

SN: A35001--UP

4шт.

17

705-17-04980

WASHER

SN: A35001--UP

4шт.

|$21

21

-1шт.

|$22

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

22

-1шт.
