Запчасти Komatsu WA320-6 C-A МОТОР ВЕНТИЛЯТОРА (/) СИСТЕМА ОХЛАЖДЕНИЯ

|$0

MOTOR ASSEMBLY (SEE FIG. C0110-10A0 )

SN: A34001--UP

-1шт.

1

07000-12095

O-RING

SN: A34001--UP

1шт.

2

720-68-19610

PIN

SN: A34001--UP

2шт.

3

01010-81070

BOLT

SN: A34001--UP

4шт.

4

708-7R-12210

SHAFT

SN: A34001--UP

1шт.

5

708-7R-12220

BEARING

SN: A34001--UP

1шт.

6

708-7S-12220

BEARING

SN: A34001--UP

1шт.

7

708-7S-05110

SHIM KIT

SN: A34001--UP

1шт.

8

708-7R-12240

SEAL, OIL

SN: A34001--UP

1шт.

9

04065-04218

RING

SN: A34001--UP

1шт.

10

708-7R-13130

BLOCK, CYLINDER

SN: A34001--UP

1шт.

11

708-7R-13610

PLATE, VALVE

SN: A34001--UP

1шт.

12

720-68-19610

PIN

SN: A34001--UP

1шт.

13

708-7R-13540

PIN

SN: A34001--UP

3шт.

14

708-7R-13530

WASHER

SN: A34001--UP

2шт.

15

708-7R-13560

SPRING

SN: A34001--UP

1шт.

16

04065-03012

RING

SN: A34001--UP

1шт.

17

708-7R-13590

GUIDE, RETAINER

SN: A34001--UP

1шт.

18

708-7R-13370

RETAINER, SHOE

SN: A34001--UP

1шт.

19

708-7R-13320

PISTON SUB ASSEMBLY

SN: A34001--UP

7шт.

20

708-7R-13620

PLATE

SN: A34001--UP

1шт.

|$21

21

-1шт.

|$22

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

22

-1шт.
