Запчасти Komatsu WA320-6 H-A ГИДР. НАСОС. ОСНОВН. НАСОС (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-02A0 )

SN: A34001--UP

-1шт.

|$1

705-41-05690

PUMP ASSEMBLY, (SBR12)

SN: A34001--UP

1шт.

1

705-41-83510

BRACKET ASSEMBLY

SN: A34001--UP

1шт.

N/I

705-40-83630

BUSHING, PLANE

SN: A34001--UP

1шт.

N/I

705-40-83640

BUSHING, PLANE

SN: A34001--UP

1шт.

2

705-40-24E70

COVER

SN: A34001--UP

1шт.

N/I

705-40-83640

BUSHING, PLANE

SN: A34001--UP

1шт.

N/I

705-40-83630

BUSHING, PLANE

SN: A34001--UP

1шт.

3

705-40-24L50

GEAR, DRIVE

SN: A34001--UP

1шт.

4

705-40-24H10

GEAR, DRIVEN

SN: A34001--UP

1шт.

5

705-40-83720

PLATE, SIDE

SN: A34001--UP

2шт.

6

705-40-80770

SEAL

SN: A34001--UP

1шт.

7

705-40-80881

PLATE

SN: A34001--UP

1шт.

8

705-40-83760

SEAL

SN: A34001--UP

1шт.

9

705-40-81820

SEAL, OIL

SN: A34001--UP

1шт.

10

705-40-81870

PLATE

SN: A34001--UP

1шт.

11

04065-03012

RING, SNAP

SN: A34001--UP

1шт.

12

01252-71055

BOLT

SN: A34001--UP

4шт.

13

01643-51032

WASHER

SN: A34001--UP

4шт.

14

04020-00514

PIN, DOWEL

SN: A34001--UP

2шт.

15

705-67-01330

COUPLING ASSEMBLY

SN: A34001--UP

1шт.

16

705-40-80670

SEAL

SN: A34001--UP

1шт.

17

01252-60830

BOLT

SN: A34001--UP

4шт.

18

01643-50823

WASHER

SN: A34001--UP

4шт.

|$24

24

-1шт.

|$25

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

25

-1шт.
